Vollrath

Vollrath Short-Sided Drop-In Hot Well for 4 Full-Size Pans, Thermostatic Controls, Standard Drain, 120V

SKU: 36644
$3,662.65
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Food Bars & Buffets Food Holding & Warming Equipment Food Wells & Serving Lines Hot Well New Arrivals Restaurant Equipment Steam Tables & Food Wells Vollrath

Vollrath Short-Sided Drop-In Hot Well for 4 Full-Size Pans, Thermostatic Controls, Standard Drain, 120V

Insulated stainless steel construction with wet operation and full perimeter drip edge

Designed for narrow buffet lines, this insulated short-sided hot well turns full-size pans sideways for easier reach while holding food at serving temperature.

  • Short-sided layout turns full-size pans sideways for a narrower presentation and easier access.
  • 4-pan capacity with an 8-inch-deep well supports high-volume buffet service.
  • Thermostatic controls help maintain consistent food-warming temperatures.
  • Thick polyurethane foam insulation and stainless steel construction help retain heat efficiently.
  • Standard drain with included drain plug simplifies cleanup and maintenance.
  • 120V, 2500W, single-phase operation with a NEMA 5-30P plug for straightforward hookup.

Overall Dimensions:

88.56"W x 18.0"D x 15.0"H

Product Weight:

173.0 lb

Short-Sided Pan Orientation

Turns full-size pans sideways to save counter depth and improve serving access.

Thermostatic Temperature Control

Helps maintain accurate warming temperatures for food service applications.

4 Full-Size Pan Capacity

Configured for four full-size pans to support buffet and serving line volume.

Insulated Stainless Steel Construction

Built with 18/8 stainless steel and thick polyurethane foam insulation to help hold heat.

Standard Drain With Drain Plug

Includes a standard drain and a drain plug for easier cleaning and maintenance.

Full Perimeter Drip Edge

Helps contain spills and keep the counter area cleaner.

Deep Drop-In Well

Features an 8-inch-deep well for effective hot food holding.

Electrical Setup

Rated at 2500 watts, 120V/60 Hz/1-phase, 20.8 amps, with a NEMA 5-30P plug.

Type Hot Well
Style Individual Pans
Pan Orientation Short Side
Installation Type Drop-In
Controls Thermostatic
Wet/Dry Operation Wet
Drain Type Standard Drain
Pan Capacity 4 Full-Size Pans
Material Stainless Steel
Voltage 120 Volts
Amps 20.8 Amps
Watts 2.5 kW
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-30P
Country of Origin USA
Selling Unit Each
Units Per Case 1
Shipping Width 89 Inches
Shipping Depth 18 Inches
Shipping Height 15 Inches
Shipping Weight 173 Pounds

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Warranty & Protection

1-year warranty

Documents

PDF Cutsheet PDF Download PDF Catalog page PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It is designed for four full-size pans.
It requires 120V/60 Hz/1-phase power, draws 20.8 amps, and uses a NEMA 5-30P plug.
Yes, it has a standard drain and includes a drain plug.
It turns full-size pans sideways for a narrower presentation and easier reach.
Yes, it uses thick polyurethane foam insulation.
No. The catalog notes modular drop-ins are designed for warming food pans only, not for use as a rethermalizing water vessel.
