Vollrath 36643 Steam Tables & Food Wells
Description
Vollrath Short-Side Drop-In Hot Well – 3-Pan
Infinite controls • Standard drains • 120 V plug-in convenienceGive guests easy access to hot entrées while saving valuable counter depth. Vollrath’s 3-well Short-Side Hot Drop-In turns three full-size steam table pans sideways, creating a slim 18-inch profile that fits tight service lines and makelines without sacrificing capacity or food-safe holding performance.
Why you’ll love it
- Side-turned wells present food just 18 inches from the counter edge for effortless reach.
- 18/8 (304 series) stainless-steel top flange & drawn wells resist corrosion and clean up fast.
- Thick polyurethane foam insulation on every side—including between wells—boosts energy efficiency.
- (3) individual infinite controls on a remote stainless panel (4 ft tether) let you dial in each well’s heat level.
- Standard ½" drains with ball valves plus included drain plug simplify daily water changes.
- Full-perimeter drip edge with factory-installed gasket protects counters from condensate.
- Ships with 6 ft cord & NEMA 5-20P plug—no hard-wiring required.
- Zero-clearance design drops into counters up to 3" thick with included mounting clips.
- UL, CUL & NSF 4 listed; proudly made in the USA.
Key specifications
| Pan capacity | 3 full-size 12" × 20" pans (accepts fractional pans with adapter bars) |
|---|---|
| Per-well wattage | 625 W |
| Total wattage / amperage | 1,875 W • 15.6 A |
| Voltage & phase | 120 V • 60 Hz • 1-phase |
| Plug type | NEMA 5-20P (straight-blade, grounded) |
| Overall dimensions | 66 7⁄8" W × 18" D |
| Cutout dimensions | 66 1⁄16" W × 17 1⁄4" D • 7⁄8" corner radius |
| Well interior (each) | 20" L × 12" W × 8" D |
| Controls | 3 independent infinite switches with power indicators |
| Drain | (3) ½" NPT drains with individual ball valves & plug |
| Construction | 18/8 stainless steel with foam insulation & perimeter gasket |
| Certifications | UL, CUL, NSF 4 |
| Origin | Made in Sheboygan, Wisconsin, USA |
• Designed for holding pre-heated foods; not intended for re-thermalizing refrigerated product.
Warranty & support
Covered by Vollrath’s standard commercial warranty. Refer to the full policy at vollrathfoodservice.com.
