Vollrath  |  SKU: 36641

Vollrath 36641 Steam Tables & Food Wells

$2,055.55
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath Short-Side 2-Pan Drop-In Hot Well

Model 36641 · Infinite Controls · 120 V

Bring your hot food forward without crowding the counter. This Vollrath short-side drop-in turns full-size pans sideways, giving you an easy-reach 18 inch depth while holding foods at safe serving temperatures.

Key Features

  • Slim 18" depth — ideal for serving lines, kiosks & tight prep stations.
  • Independent infinite controls for precise holding in each well.
  • 18/8 stainless-steel flange & wells resist corrosion and wipe clean fast.
  • Thick polyurethane foam insulation on every non-exposed side (and between wells) boosts efficiency.
  • Full-perimeter drip edge with factory gasket keeps condensate off the counter.
  • ½" standard drains with individual ball valves; drain plug included for quick daily clean-out.
  • Zero-clearance, top-mount installation — mounting clips & 6 ft cord with NEMA 5-15P plug included (no hard-wiring).
  • Accepts two full-size or assorted fractional pans up to 6" deep; adapter bars recommended for fractional pans.
  • UL, cUL & NSF listed — built in the USA for commercial foodservice.

Specifications

Capacity (2) full-size wells, 20" × 12" each; 8" (20.3 cm) deep
Total Wattage 1,250 W (625 W per well)
Electrical 120 V / 60 Hz / 1-ph, 10.4 A, NEMA 5-15P
Controls Remote stainless panel, infinite knob & power light for each well
Drain ½" standard drains with individual ball valves; plug included
Overall Dimensions (W × D) 45-1/2" × 18" (115.6 cm × 45.7 cm)
Counter Cut-Out 44-11/16" × 17-1/4" (113.5 cm × 43.8 cm) — 7/8" corner radius
Construction 18/8 (304) stainless steel; polyurethane foam insulated
Certifications UL, cUL, NSF
Country of Origin Made in USA

Operate with water for even heat distribution and NSF 4 compliance. Designed for holding pre-heated foods only.

See vollrathfoodservice.com for complete warranty details and accessory options such as the sheet-pan adapter (Item 19186).

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

15.0in

Width

45.44in

Depth

18.0in

Shipping Weight

117.0lbs

Controls

infinite controls

Style

individual pans

Construction

stainless steel construction

Insulated or Non-Insulated

insulated

Drain

with drain

Pan Capacity

(2) full size (12" x 20")

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (2) pan, infinite controls, standard drains, 1250 watts, 120v/60/1-ph, 10.4 amps, NEMA 5-15P, turns full size pans sideways for more narrow presentation & easy reach, 18/8 stainless steel, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 45-1/2" x 18", cutout dimensions 44-11/16" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
