Vollrath  |  SKU: 36640HD

Vollrath 36640HD Steam Tables & Food Wells

$2,386.35
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath Short-Side Marine-Grade Hot Well Drop-In – 2-Pan

Model 36640HD  |  Thermostatic Controls  |  Standard Drain

Maximize counter space without sacrificing holding power. This 2-well drop-in turns full-size pans sideways for a narrow 18-inch footprint, while 316 marine-grade stainless steel delivers unmatched corrosion resistance for coastal, high-humidity or aggressive cleaning environments.

Key advantages

  • Rotated wells create a slim 18 in (45.7 cm) front-to-back profile for easy pan access.
  • Drawn wells and 18-gauge top are SAE Type-316 marine-grade stainless steel – built to resist salt and acidic foods.
  • Independent thermostatic controls with power indicator lights maintain safe serving temperatures.
  • Thick polyurethane foam insulation (including between wells) improves efficiency and keeps outer surfaces cool.
  • Full-perimeter drip edge, under-mount gasket and individual ½″ ball-valve drains keep counters clean and dry.
  • Plug-and-play: 6 ft (1.8 m) cord with NEMA 5-15P plug – no hard-wiring required.
  • Zero-clearance design plus included mounting clips for counters up to 3″ (7.6 cm) simplify installation.
  • Removable service panel beneath each well for quick access to components.
  • Made in the USA and listed to UL, cUL & NSF 4 standards.

Specifications

Pan capacity 2 full-size steam table pans (side-loaded)
Total wattage 1,250 W (625 W per well)
Electrical 120 V / 60 Hz / 1-phase  |  10.4 A  |  NEMA 5-15P
Well size (each) 20″ × 12″ × 8″ D (50.8 × 30.5 × 20.3 cm)
Overall dimensions 45-1/2″ W × 18″ D
Countertop cutout 44-11/16″ W × 17-1/4″ D  |  7/8″ corner radius
Construction 316 marine-grade S/S wells & 18-ga. top, stainless exterior housing
Controls Remote stainless panel, 4 ft tether, independent thermostats & indicators
Drain ½″ drains with ball valves & removable plug (one per well)
Certifications UL, cUL, NSF 4 (moist heat only)
Origin / Warranty Made in USA  |  2-year limited warranty*

Ideal for

  • QSR and grab-and-go counters where depth is limited
  • Seafood or coastal operations needing superior corrosion resistance
  • Front-of-house cook-to-order or finishing stations
Important: Maintain moist heat (water in wells) for NSF compliance and even food temperature. Designed for holding pre-heated foods; not for re-thermalizing.

*See the complete warranty policy at vollrathfoodservice.com. Modular drop-ins are custom built to order and are not cancellable or returnable.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

15.0in

Width

45.44in

Depth

18.0in

Shipping Weight

115.0lbs

Controls

thermostatic controls

Style

individual pans

Insulated or Non-Insulated

insulated

Construction

stainless steel construction

Drain

with drain

Pan Capacity

(2) full size (12" x 20")

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (2) pan, thermostatic controls, standard drains, 1250 watts, 120v/60/1-ph, 10.4 amps, NEMA 5-15P, turns full size pans sideways for more narrow presentation & easy reach, 18 gauge/316 marine grade stainless steel top, stainless steel exterior housing, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 45-1/2" x 18", cutout dimensions 44-11/16" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
