Vollrath 36505208 Steam Tables & Food Wells
$3,417.60
Unit price
/
Unavailable
Description
Vollrath Modular Bain Marie Hot Drop-In – 5-Pan, 208 V
Item #36505208 • Top-mount, wet operation holding wellBuilt for high-volume kitchens that demand dependable hot food holding, this Made-in-USA Bain Marie Drop-In from Vollrath keeps up to five full-size pans of product at safe serving temperatures—without hard-wiring, complicated installation, or messy countertop condensation.
Why you’ll love it
- Five-pan capacity – holds full-size (or fractional with templates) pans up to 6" (15.24 cm) deep
- True wet operation – add ½" of water for even, NSF 4 compliant heating
- 18-ga 300-series stainless steel top with ⅜" drip-edge keeps spills off your counter
- 6 ⅝" (16.8 cm) deep stainless steel well surrounded by high-density glass-fiber insulation for zero-clearance installs
- Thermostatic control panel can stay on the unit or be remote-mounted (48" flexible cord included)
- Individual 625 W heating elements (total 3,125 W) deliver quick recovery while using less energy
- 1" NPT drain with ball-valve shut-off speeds water changes and cleaning
- Factory-installed gasket, adjustable mounting clips (up to 3" counters) & positioning clips simplify drop-in installation
- 6-ft (182.8 cm) power cord with NEMA 6-20P plug—no electrician required
- Galvanized 20-ga exterior housing resists corrosion in humid environments
Technical Specifications
| Capacity | (5) full-size steam table pans |
|---|---|
| Operating Mode | Wet (Bain Marie style) |
| Overall Dimensions (L × W) | 68" × 26" (172.7 cm × 66 cm) |
| Usable Well Length | 63" (160 cm) |
| Well Depth | 6 ⅝" (16.8 cm) |
| Electrical | 208 V / 60 Hz / 1-ph, 3,125 W, 15 A |
| Power Connection | NEMA 6-20P, 6-ft (1.83 m) cord |
| Controls | Thermostatic dial, power indicator light; on-unit or remote |
| Materials | Top & well: 18-ga 300-series stainless steel Exterior housing: 20-ga galvanized steel |
| Insulation | High-density glass fiber (sides & below element) |
| Drain | 1" NPT with ball valve (below exterior housing) |
| Certifications | cULus Listed, NSF 4 |
| Country of Origin | Made in the USA |
| Warranty | 1-year parts & labor (see vollrathfoodservice.com for details) |
Designed for holding pre-heated foods only; not intended as a re-thermalizing vessel.
Important: Modular drop-ins are built to order and cannot be cancelled or returned once your order is placed.
Features & Specs
Features & Specs
Manufacturer
Vollrath
Certifications
NSF, cULus, Made in USA
Height
15.63in
Width
68.0in
Depth
26.0in
Shipping Weight
171.0lbs
Style
bain-marie
Pan Capacity
(5) full size (12" x 20")
Controls
thermostatic controls
Construction
stainless steel top, corrosion resistant steel exterior
Insulated or Non-Insulated
insulated
Drain
with drain
Wet or Dry operation
wet
Specifications
Bain Marie Hot Drop-In, electric, top mount, (5) pan capacity, wet operation, thermostatic control (on unit or may be remote mounted with 48"control cord), fully insulated, stainless steel top & interior liner, galvanized exterior housing, 1" drain with ball valve shut off, 208v/60/1ph, 3125 watts, 15 amps, cord with NEMA 6-20P, cULus, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
