Vollrath 3640970 Steam Tables & Food Wells
$5,388.35
Unit price
/
Unavailable
Description
Vollrath 6-Well Drop-In Hot Food Well – Manifold Drain, 208 V
Model 3640970 | Individual Thermostatic ControlsKeep entrées, sides and sauces at safe, appetizing temperatures with Vollrath’s U.S-made six-well hot food module. Designed for wet operation only, each 12" × 20" well is independently controlled, giving you precise holding flexibility for a busy service line, cafeteria or buffet.
Why You’ll Love It
- Six 20-gauge stainless-steel wells fit full-size or fractional pans up to 6" deep.
- Independent thermostatic controls with power indicator lights for accurate, energy-efficient holding.
- 1" copper manifold drain with individual well shut-offs plus a master shut-off simplifies daily cleanup.
- 18-gauge stainless-steel top with full-perimeter drip-free flange contains spills and condensation.
- High-density glass-fiber insulation on all sides allows zero-clearance installation.
- Ships ready to install—includes mounting & positioning clips, 6 ft power cord and NEMA 6-30P plug.
- NSF 4 & cULus listed; proudly Made in the USA.
Technical Specifications
| Overall dimensions | 81 ¼" W × 26" D × 21 ½" H (206.4 × 66 × 54.5 cm) |
|---|---|
| Cutout size | 80 ½" W × 25 ¼" D (204.5 × 64.1 cm) • 7⁄8" corner radius required |
| Well size (each) | 12" × 20"; 6" (15.2 cm) pan depth capacity |
| Operation | Wet heat only |
| Heat output | 625 W per well • 3 750 W total |
| Voltage / phase | 208 V / 60 Hz / 1-ph |
| Amperage | 18.0 A |
| Power connection | 6 ft cord with NEMA 6-30P plug |
| Materials | Top: 18 ga stainless steel • Wells: 20 ga stainless steel • Exterior housing: 18 ga galvanized |
| Drain | 1" copper manifold, individual well shut-offs + manifold shut-off |
| Agency listings | NSF 4, cULus |
| Country of origin | USA |
Installation & Operation Notes
- Mounts flush in countertops up to 3" thick using the included adjustable clips.
- Unit must be operated with water in each well to meet NSF performance standards and ensure even heating.
- Adaptor bars are recommended when using fractional pans (sold separately).
- Modular drop-ins are custom-built and cannot be cancelled or returned.
Warranty
Includes Vollrath’s standard one-year parts & labor warranty. See full policy at vollrathfoodservice.com.
Important: This unit is designed for wet operation only.
Running wells dry may cause element damage and void the warranty.
Features & Specs
Features & Specs
Manufacturer
Vollrath
Certifications
NSF, cULus, Made in USA
Height
21.5in
Width
81.25in
Depth
26.0in
Shipping Weight
300.0lbs
Pan Capacity
(6) full size (12" x 20")
Controls
thermostatic controls
Style
individual pans
Insulated or Non-Insulated
insulated
Construction
stainless steel top, corrosion resistant steel exterior
Drain
with drain
Wet or Dry operation
wet
Specifications
Hot Food Well Unit, Drop-In, electric, (6) 12" x 20" individual 20 gauge stainless steel insulated wells, 81-1/4"W x 26"D x 21-1/2"H (overall), wet operation only, individual thermostatic controls mounted in panel with cord, power indicator light, drip-free flange, 1" copper manifold drain with individual well shutoffs & manifold shutoff, 18 gauge stainless steel top, 18 gauge galvanized exterior housing, includes positioning clips, 3750 watts, 208v/60/1-ph, 18.0 amps, cord with NEMA 6-30P, NSF, cULus, Made in USA (80-1/2"W x 25-1/4"D cutout size, requires 7/8" corner radius) (Refer to vollrathfoodservice.com for full warranty policy)
