Vollrath 36260 4-Series Signature Server® Serving Counters
Description
4-Series Signature Server® Cold Food Station – 60" Stainless Top
Model 36260 • 4-Pan Ice-Cold Well • 27" Low Profile HeightBuilt for high-volume salad bars, deli lines and grab-and-go merchandising, the 4-Series Signature Server® keeps product safely chilled and beautifully displayed—all in a compact, operator-friendly footprint.
Why You’ll Love It
- 60" W x 28" D modular base fits seamlessly into new or existing serving lines.
- Ice-cooled 19 ⅞" × 50 ¼" × 8" deep stainless well with a 4-pan opening (holds four full-size 12" × 20" pans).
- Pitched bottom, drain hose and shut-off valve are all accessed from the operator side—no mess on the customer side.
- Durable construction:
- 18-ga 400-series stainless steel enclosed base
- One-piece 300-series stainless well & countertop
- Foamed-in-place polyurethane insulation for maximum cold retention
- Integrated ¼ HP refrigeration system with eco-friendly R290 refrigerant (low GWP).
- 8 ft (2.4 m) power cord with NEMA 5-15P plug—no hardwiring required.
- 4" swivel casters (two locking) let you roll the unit wherever service demands.
- NSF 2 listed, cULus certified and proudly Made in the USA.
At-a-Glance Specs
| Exterior Dimensions | 60" W × 28" D × 27" H (152 × 71 × 69 cm) |
|---|---|
| Well Size (usable) | 19 ⅞" W × 50 ¼" L × 8" D (50.5 × 127.6 × 20.3 cm) |
| Pan Capacity | (4) Full-size 12" × 20" pans (not included) |
| Cooling Method | Pitched ice bath with ¼ HP remote refrigeration, R290 |
| Electrical | 120 V / 1 ph / 5.5 A • NEMA 5-15P |
| Construction | 18-ga base, 300-series well & top, foamed-in insulation |
| Mobility | (4) 4" swivel casters, 2 with brakes |
| Certifications | NSF 2, cULus |
| Country of Origin | USA |
Installation & Use
- Provide at least 3" clearance in front of ventilation panels for proper airflow.
- Position the unit away from drafts and HVAC returns for best cold-holding performance.
- Do not modify the factory-installed cord or plug.
Warranty
Covered by Vollrath’s standard limited warranty—5 years on the compressor, 1 year on remaining parts & labor. See vollrathfoodservice.com for full details.
Breath guards, pans and décor shown in photos are sold separately.
