Vollrath 36146 4-Series Signature Server® Serving Counters
Description
Vollrath 4-Series Signature Server® NSF7 Cold Station – 46" x 28"
Self-Contained Stainless Steel Refrigerated Counter, 30" Base HeightBring reliable, energy-efficient cold holding to your serving line with Vollrath’s 4-Series Signature Server® Cold Station. Engineered for commercial kitchens that demand mobility, durability and flawless temperature performance, this 46-inch unit keeps pre-chilled foods safely below 41 °F while showcasing them in a sleek Bloomington-style recessed well.
Key features & benefits
- NSF 7 certified open-top refrigerator for safe cold holding at 41 °F (5 °C) or below.
- One-piece stainless steel countertop with 18-ga 400-series base and 300-series seamless well for long-term corrosion resistance.
- Bloomington-style well positions pans 3" below the work surface, protecting food with a natural cold-air curtain.
- Self-contained 1/5 HP refrigeration system with eco-friendly R290 refrigerant and heavy-duty coils wrapped around the side walls for even 360° cooling.
- Accepts standard 6" (150 mm) deep hotel pans; well opening measures 19 7⁄8" × 37 1⁄2" × 6 5⁄8" (505 × 952 × 168 mm).
- Foamed-in-place polyurethane insulation improves energy efficiency and holds temperature during rush periods.
- 1" integral drain with operator-side hose/valve speeds clean-up at the end of service.
- 4" locking swivel casters make the unit easy to reposition and stable during use.
- 8 ft (2.4 m) cord and NEMA 5-15P plug; draws only 3.8 A on a standard 120 V outlet.
- cULus listed, Made in the USA, and backed by a 5-year compressor warranty.
Technical specifications
| Model / Item # | 36146 (4-Series, 30" base height) |
|---|---|
| Exterior dimensions | 46" W × 28" D × 30" H (117 × 71 × 76 cm) |
| Well opening | 19 7⁄8" W × 37 1⁄2" L × 6 5⁄8" D |
| Pan capacity | Designed for standard 6" deep steam-table pans (configuration varies) |
| Compressor | 1/5 HP, R290 refrigerant |
| Electrical | 120 V / 60 Hz / 1-phase, 3.8 A, NEMA 5-15P |
| Certifications | NSF 7, cULus |
| Clearance requirement | 3" minimum in front of ventilation louvers |
| Country of origin | USA |
Ideal for
- School and university cafeterias
- Healthcare tray lines
- Corporate dining and catering operations
- Supermarket grab-and-go stations
- Any operation that needs a mobile, plug-and-play refrigerated drop-in
Full warranty details are available at VollrathFoodservice.com.
