Victory Refrigeration

Victory Refrigeration VBBN72HC-F-PT-S 72-Inch Pass-Thru Back Bar Refrigerator, 6 Solid Doors, Stainless Steel

SKU: VBBN72HC-F-PT-S
$11,989.26
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Victory Refrigeration VBBN72HC-F-PT-S is a three-section, food-rated pass-thru back bar refrigerator with a stainless steel exterior, interior, and 1-inch stainless steel top.

It has six solid self-closing doors with a 120-degree stay-open feature, magnetic door gaskets, door locks, full electronic control, LED lighting, and six epoxy-coated steel shelves. The balanced forced-air refrigeration system uses R-290 hydrocarbon refrigerant and is specified to maintain product temperatures from 36°F to 38°F.

  • 19.618 cu. ft. capacity
  • Storage for three 1/2-barrel kegs
  • Self-contained, side-mounted refrigeration
  • 115V electrical system with NEMA 5-15P plug
  • Certified for open food product

Overall Dimensions:

72.0"W x 29.56"D x 34.0"H

Product Weight:

421.0 lb

Pass-thru, food-rated design

Three-section back bar refrigerator specified for pass-thru use and certified for open food product.

Six solid doors

Six solid self-closing doors include a 120-degree stay-open feature, magnetic door gaskets, and door locks.

Temperature control

Full electronic control; the refrigerator is capable of maintaining product temperatures from 36°F to 38°F.

Forced-air refrigeration

Balanced, forced-air refrigeration with adaptive defrost and an epoxy-coated evaporator coil.

Storage configuration

Includes six epoxy-coated steel shelves and capacity for three 1/2-barrel kegs.

Stainless steel construction

Stainless steel exterior, stainless steel interior, and standard 1-inch stainless steel top.

LED lighting

Interior LED lighting is specified for the cabinet.

Self-contained refrigeration

The refrigeration system is self-contained and side-mounted, with the compressor standard on the left side.

Electrical connection

115V, 60 Hz, single-phase operation at 3.3 amps with a NEMA 5-15P plug.

ADA compliance

The cutsheet identifies the standard-height cabinet as ADA compliant.

Related Searches

Back Bar Coolers Back Bar Coolers Back-Bar & Bottle Cooling Equipment Back-Bar Refrigerators Bar & Beverage Refrigeration Bar Equipment Bar Refrigeration Best Sellers Commercial Refrigeration Commercial Refrigerators New Arrivals Refrigeration & Ice Restaurant Equipment Victory Refrigeration
Product Type Pass-thru back bar refrigerator
Construction Food-rated
Sections Three
Door Count 6 doors
Door Type Solid
Door Configuration Self-closing; 120-degree stay-open feature
Door Gasket Magnetic
Door Locks Included
Capacity 19.618 cu. ft.
Shelves 6 epoxy-coated steel shelves
Keg Capacity 3 half-barrel kegs
Lighting LED
Controls Full electronic control
Temperature Range 36°F to 38°F
Refrigeration System Balanced, forced-air; adaptive defrost
Refrigeration Location Self-contained, side-mounted
Compressor Location Left side
Refrigerant R-290 hydrocarbon
Compressor Size 1/3 HP
Amperage 3.3 A
Voltage 115 V
Frequency 60 Hz
Phase 1-ph
Plug Type NEMA 5-15P
Exterior Finish Stainless steel
Interior Finish Stainless steel
Top Finish 1-inch stainless steel
Internal Usable Width 57 in
Internal Depth 19.5 in
Internal Height 30.5 in
Certification UL EPH Classified; cULus

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

The cutsheet lists an exclusive 7-year parts, labor, and compressor warranty.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

It has six solid self-closing doors with a 120-degree stay-open feature, magnetic door gaskets, and door locks.
The cabinet has 19.618 cu. ft. of capacity and is specified for three 1/2-barrel kegs.
The refrigerator is capable of maintaining product temperatures from 36°F to 38°F.
It operates at 115V, 60 Hz, single phase, draws 3.3 amps, and uses a NEMA 5-15P plug.
It uses R-290 hydrocarbon refrigerant.
Yes. It includes six epoxy-coated steel shelves and LED lighting.
