Victory Refrigeration VBBN48HC-PT-B 48-Inch Pass-Thru Back Bar Refrigerator, 4 Solid Self-Closing Doors, Stainless Steel Top, Black Exterior

SKU: VBBN48HC-PT-B
$7,541.70
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

VBBN48HC-PT-B is a 48-inch, two-section pass-thru back bar refrigerator with 12.56 cu. ft. net capacity. It has four solid self-closing doors with a 120° stay-open feature, magnetic door gaskets, door locks, LED lighting, and four epoxy-coated steel shelves.

The unit features a 1-inch stainless steel top, black exterior, galvanized interior, stainless steel floor, R-290 refrigerant, and full electronic control.

  • Holds two 1/2-barrel kegs.
  • Uses 115/60/1-ph power, 3 amps, and a NEMA 5-15P plug.

Overall Dimensions:

48.0"W x 29.56"D x 34.0"H

Product Weight:

320.0 lb

Pass-thru configuration

Two-section design identified as a pass-thru back bar refrigerator.

Solid self-closing doors

Four solid doors include a 120° stay-open feature.

Door sealing and security

Magnetic door gaskets and door locks are specified.

Electronic refrigeration control

Full electronic control and adaptive defrost are specified.

Storage shelves

Includes four epoxy-coated steel shelves.

Interior and exterior construction

Features a black painted steel exterior, galvanized steel interior, and stainless steel floor.

Stainless steel top

Includes a standard 1-inch stainless steel top.

Keg storage

Rated for two 1/2-barrel kegs.

LED lighting

Interior LED lighting is specified.

Electrical connection

Uses 115/60/1-ph power at 3 amps with a NEMA 5-15P plug.

Related Searches

Back Bar Coolers Back Bar Coolers Back-Bar & Bottle Cooling Equipment Back-Bar Refrigerators Bar & Beverage Refrigeration Bar Equipment Bar Refrigeration Best Sellers Commercial Refrigeration Commercial Refrigerators New Arrivals Refrigeration & Ice Restaurant Equipment Victory Refrigeration
Product Type Pass-thru back bar refrigerator
Configuration Two-section
Net Capacity 12.56 cu. ft.
Door Count 4
Door Type Solid
Door Style Swing
Door Operation Self-closing
Door Feature 120° stay-open feature
Door Sealing and Security Magnetic door gaskets and door locks
Shelf Count 4
Shelf Construction Epoxy-coated steel
Keg Capacity 2 half barrels
Temperature Range 36°F to 38°F
Control Type Full electronic
Defrost Adaptive
Lighting LED
Exterior Finish Black painted steel
Interior Construction Galvanized steel
Interior Floor Stainless steel
Top Finish 1-inch stainless steel
Refrigeration System Balanced, forced-air
Refrigerant R-290 hydrocarbon
Refrigeration Location Self-contained, side mounted
Compressor Location Left side standard
Compressor Size 1/4 HP
Electrical 115/60/1-ph
Current 3 amps
Plug NEMA 5-15P with 8-foot cord
Application Packaged products only

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

The exact-model cutsheet lists an exclusive 7-year parts, labor and compressor warranty, a 2-year warranty on magnetic door gaskets, and a lifetime parts-only warranty on handles and hinges.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

Yes. The VBBN48HC-PT-B is identified as a pass-thru back bar refrigerator.
It has four solid self-closing doors with a 120° stay-open feature.
The net capacity is 12.56 cu. ft.
The unit is specified for two 1/2-barrel kegs.
It uses 115/60/1-ph power, draws 3 amps, and has a NEMA 5-15P plug.
It uses R-290 hydrocarbon refrigerant.
The compressor is standard on the left side.
The exact-model cutsheet lists a 7-year parts, labor and compressor warranty, a 2-year warranty on magnetic door gaskets, and a lifetime parts-only warranty on handles and hinges.
