Victory Refrigeration

Victory Refrigeration VBBN48HC-G-PT-B Pass-Thru Back Bar Refrigerator, 4 Glass Doors, 48"W, Black Exterior, Stainless Steel Top

SKU: VBBN48HC-G-PT-B
$9,482.81
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Victory Refrigeration VBBN48HC-G-PT-B is a two-section pass-thru back bar refrigerator with 12.56 cu. ft. of capacity, four self-closing glass doors, and a 1-inch stainless steel top.

  • Door features: Four glass doors include a 120° stay-open feature, magnetic gaskets, and locks.
  • Storage: Includes four epoxy-coated steel shelves and capacity for two half-barrel kegs.
  • Refrigeration: Uses R-290 hydrocarbon refrigerant, adaptive defrost, full electronic control, and LED lighting.
  • Construction: Features a black exterior finish and stainless steel top.
  • Electrical: Operates at 115 V, 60 Hz, single phase, with a NEMA 5-15P plug.

Overall Dimensions:

48.0"W x 28.75"D x 34.0"H

Product Weight:

329.0 lb

Pass-thru configuration

Two-section back bar refrigerator identified as a pass-thru model.

Self-closing glass doors

Four glass doors include a 120° stay-open feature, magnetic door gaskets, and locks.

Storage capacity

Provides 12.56 cu. ft. of capacity, four epoxy-coated steel shelves, and space for two half-barrel kegs.

Electronic refrigeration control

Includes full electronic control, adaptive defrost, and LED lighting.

Refrigeration system

Uses R-290 hydrocarbon refrigerant with a balanced, forced-air refrigeration system and a 1/4 HP condensing unit.

Exterior and top construction

Features a black exterior finish and a 1-inch stainless steel top.

Electrical configuration

Rated at 115 V, 60 Hz, single phase, 3 A, with a NEMA 5-15P plug.

Product application

The specification sheet identifies the unit for packaged products only.

Related Searches

Back Bar Coolers Back Bar Coolers Back-Bar & Bottle Cooling Equipment Back-Bar Refrigerators Bar & Beverage Refrigeration Bar Equipment Bar Refrigeration Best Sellers Commercial Refrigeration Commercial Refrigerators New Arrivals Refrigeration & Ice Restaurant Equipment Victory Refrigeration
Product type Pass-thru back bar refrigerator
Configuration Two-section
Net capacity 12.56 cu. ft.
Door quantity 4 doors
Door type Glass
Door operation Self-closing with 120° stay-open feature
Door gasket Magnetic
Door locks Included
Shelves 4 epoxy-coated steel shelves
Keg capacity 2 half-barrel kegs
Control type Full electronic control
Lighting LED
Exterior finish Black exterior
Top material 1-inch stainless steel
Refrigeration location Self-contained, side mounted
Defrost Adaptive
Refrigerant R-290 hydrocarbon
Condensing unit size 1/4 HP
Temperature range 36°F to 38°F
Total amperage 3 A
Voltage 115 V
Frequency and phase 60 Hz, single phase
Plug NEMA 5-15P
Power cord 8 ft.
Product application Packaged products only
Crated weight 329 lb

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

7-year parts, labor, and compressor warranty; 2-year warranty on magnetic door gaskets; lifetime parts-only warranty on handles and hinges.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

The unit is 48 in. wide x 28.75 in. deep x 34 in. high.
It has four self-closing glass doors with a 120° stay-open feature, magnetic gaskets, and door locks.
The refrigerator has 12.56 cu. ft. of capacity and is specified for two half-barrel kegs.
It operates at 115 V, 60 Hz, single phase, draws 3 A, and uses a NEMA 5-15P plug.
It uses R-290 hydrocarbon refrigerant.
