Victory Refrigeration VBBN48HC-F-PT-S 48-Inch Pass-Thru Back Bar Refrigerator, 4 Solid Self-Closing Doors, Stainless Steel

SKU: VBBN48HC-F-PT-S
$10,444.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Victory Refrigeration VBBN48HC-F-PT-S is a food-rated, two-section pass-thru back bar refrigerator with a 12.56 cu. ft. capacity.

  • Door configuration: Four solid self-closing doors feature a 120° stay-open position, magnetic gaskets, and door locks.
  • Storage: Includes four epoxy-coated steel shelves and capacity for two 1/2-barrel kegs.
  • Construction: Stainless steel exterior, interior, and 1-inch stainless steel top.
  • Refrigeration: Full electronic control, adaptive defrost, LED lighting, and R-290 hydrocarbon refrigerant.
  • Electrical: 115 V / 60 Hz / 1 ph, 3 amps, with a NEMA 5-15P plug.

Overall Dimensions:

48.0"W x 29.56"D x 34.0"H

Product Weight:

320.0 lb

Pass-thru design

Food-rated, two-section back bar refrigerator designed as a pass-thru unit.

Solid self-closing doors

Four solid doors include a 120° stay-open feature, magnetic gaskets, and door locks.

Refrigerated storage

Provides 12.56 cu. ft. of net capacity, four epoxy-coated steel shelves, and storage for two 1/2-barrel kegs.

Temperature control

Full electronic control and adaptive defrost; the refrigerator is capable of maintaining 36°F to 38°F product temperature.

Stainless steel construction

Features a stainless steel exterior, stainless steel interior, and 1-inch stainless steel top.

Forced-air refrigeration

Balanced, forced-air refrigeration system with a side-mounted, self-contained refrigeration location.

LED lighting

Interior LED lighting is included.

Electrical connection

Operates at 115 V / 60 Hz / 1 ph and 3 amps with a NEMA 5-15P plug.

Related Searches

Back Bar Coolers Back Bar Coolers Back-Bar & Bottle Cooling Equipment Back-Bar Refrigerators Bar & Beverage Refrigeration Bar Equipment Bar Refrigeration Best Sellers Commercial Refrigeration Commercial Refrigerators New Arrivals Refrigeration & Ice Restaurant Equipment Victory Refrigeration
Product Type Pass-thru back bar refrigerator
Application Food rated
Sections Two-section
Net Capacity 12.56 cu. ft.
Door Quantity 4 doors
Door Type Solid
Door Operation Self-closing
Door Stay-Open Feature 120°
Shelves 4 epoxy-coated steel shelves
Keg Capacity 2 half-barrel kegs
Temperature Range 36°F to 38°F
Refrigeration Location Self-contained, side mounted
Control Type Full electronic control
Defrost Adaptive
Refrigerant R-290 hydrocarbon
Condensing Unit Size 1/4 HP
Electrical 115 V / 60 Hz / 1 ph
Current 3 amps
Plug Type NEMA 5-15P
Exterior Finish Stainless steel exterior
Interior Finish Stainless steel interior
Top Finish 1-inch stainless steel top
Overall Width 48 in
Overall Depth 29.56 in
Overall Height 34 in
Weight 320 lb

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

The cutsheet lists an exclusive 7-year warranty covering parts, labor, and compressor.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

Yes. The exact model is identified as food rated, and the cutsheet states that it is certified for open food product.
It has four solid self-closing doors and four epoxy-coated steel shelves.
The refrigerator has 12.56 cu. ft. of net capacity and accommodates two 1/2-barrel kegs.
It uses 115 V / 60 Hz / 1 ph power at 3 amps and includes a NEMA 5-15P plug.
The cutsheet lists an exclusive 7-year warranty covering parts, labor, and compressor, plus a 2-year warranty on magnetic door gaskets and a lifetime warranty on handles and hinges for parts only.
