Victory Refrigeration UltraSpec™ ACRS-1D-S1-SD-HC One-Section Refrigerator Air Curtain, Bottom-Mounted Self-Contained, Stainless Steel

SKU: ACRS-1D-S1-SD-HC
$17,011.37
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Victory UltraSpec™ ACRS-1D-S1-SD-HC is a one-section refrigerator air curtain with 13.6 cu. ft. of capacity and bottom-mounted self-contained refrigeration.

It features stainless steel interior and exterior construction, a full-height solid stainless steel door that swings open 90° and slides back to hide away, full electronic control, and a heavy-duty cylinder lock.

  • Fifteen adjustable stainless steel pan slides accommodate 18 x 26 in. trays; pans are not included.
  • R-290 hydrocarbon refrigerant and adaptive defrost technology.
  • 7 1/4 in. heavy-duty casters with locks.
  • 115/60/1-ph electrical service, 8.7 A, NEMA 5-20P, and a 10 ft. cord and plug.

Overall Dimensions:

36.0"W x 43.0"D x 87.0"H

Product Weight:

562.0 lb

Door design

The full-height solid stainless steel door swings open 90° and offers a slide-back option to hide away.

Electronic control

Full electronic control with a manager’s lockout feature.

Refrigeration system

Bottom-mounted self-contained refrigeration powered by V-Core™ and using R-290 refrigerant.

Temperature management

Adaptive defrost and expansion valve technology are included.

Pan slides

Fifteen adjustable stainless steel pan slides accommodate 18 x 26 in. trays; pans are not included.

Door security

Heavy-duty cylinder lock.

Exterior thermometer

Exterior digital thermometer.

Door-open operation

The cutsheet states that the unit can maintain product temperatures at or below 41°F for up to 90 minutes with the door open under 80°F and 55% relative humidity ambient conditions, when used as directed.

Related Searches

Air Doors Best Sellers Display Refrigeration Kitchen Ventilation & Climate Control New Arrivals Open-Air Refrigerated Merchandisers Refrigerated Merchandiser Equipment Refrigeration & Ice Restaurant Equipment Victory Refrigeration
Series UltraSpec™
Product type Refrigerator air curtain, solid sliding door
Sections 1
Capacity 13.6 cu. ft.
Refrigeration Bottom-mounted self-contained refrigeration
Compressor location Bottom mounted
Compressor horsepower 3/4 HP
Refrigerant R-290 hydrocarbon
Door (1) full-height solid stainless steel hinged door with slide-back option
Door lock Heavy-duty cylinder lock
Exterior finish Stainless steel
Interior finish Stainless steel
Control Full electronic control
Pan slide capacity 15 adjustable pan slides for 18 x 26 in. trays
Caster size 7 1/4 in. heavy-duty locking casters
Electrical 115/60/1 ph
Current 8.7 A
Plug NEMA 5-20P
Power cord 10 ft. cord and plug

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of UL Certified
UL Certified

Warranty & Protection

Seven-year parts, labor, and compressor warranty, plus a separate two-year warranty on magnetic door gaskets.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The refrigerator has a 13.6 cu. ft. capacity.
It uses bottom-mounted self-contained refrigeration with R-290 hydrocarbon refrigerant.
The unit is rated at 115/60/1 ph and 8.7 A, with a NEMA 5-20P plug and a 10 ft. cord.
It has 15 pan-slide positions for 18 x 26 in. trays. Pans are not included.
The full-height solid stainless steel door swings open 90° and has a slide-back option to hide away.
The cutsheet lists a seven-year parts, labor, and compressor warranty, a separate two-year warranty on magnetic door gaskets, and a lifetime parts-only warranty on handles and hinges.
