Key specifications

Amps
2 Amps (Repressurization Pump)
Type
Reverse Osmosis System
Installation Type
Wall Mounted
Daily Production
350 GPD
Tank Size
16 Gallons
Storage Tank Type
Atmospheric
Spec sheet
UNOX SKU: UX164-14416CRA

UNOX UX164-14416CRA 350 GPD Reverse Osmosis System with 16-Gallon Atmospheric Storage Tank

$5,249.24
/each
Estimated to ship in 4–7 business days
Included: UNOX warranty Standard Pentair Limited Warranty with 60-month coverage for system components and assembly

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $486/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Call (888) 307-5030 Call

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Call (888) 307-5030 Call

Specifications

Type Reverse Osmosis System
Installation Type Wall Mounted
Daily Production 350 GPD
Tank Size 16 Gallons
Storage Tank Type Atmospheric
Voltage 120 Volts
Watts 6 Watts (Water Processor)
Amps 2 Amps (Repressurization Pump)
Hertz 60 Hz
TDS Rejection >97%
Operating Pressure Range 60-85 psi
Inlet Water Temperature Range 40-100°F
Feedwater Connection 3/8 in Push-Fit Tubing
Drain Flow 2.0 GPM Minimum
Feed TDS Up to 1,200 ppm
Feed pH 6-10
Water Hardness 12 grains or less

Description

The UNOX UX164-14416CRA is a wall-mounted reverse osmosis system that produces up to 350 gallons per day and includes a 16-gallon atmospheric storage tank. Integrated prefiltration provides particulate and chlorine reduction, followed by reverse osmosis and mineral addition.

  • Dual-read digital TDS meter displays membrane performance and optimized water quality.
  • Built-in full-system bypass valve and adjustable reject-flow control support maintenance and water-use adjustment.
  • The storage tank includes a top-mounted variable-flow repressurization system, sub-micron air breather, and low-water-level pump protection switch.

Product Weight:

25.0 lb

Reverse Osmosis Filtration

Uses reverse osmosis with typical TDS rejection greater than 97%.

Integrated Prefiltration

Dual/parallel prefilters reduce particulate and chlorine before reverse osmosis.

Mineral Addition

An integrated mineral-addition cartridge adds minerals to the product water.

Digital TDS Monitoring

Dual-read digital TDS meter displays RO membrane performance and optimized water quality.

System Bypass

Built-in full-system bypass valve helps maintain service access without a system interruption.

Reject Flow Control

Adjustable reject-flow control allows adjustment of the product-to-reject ratio.

Storage Tank Repressurization

The atmospheric storage tank uses a top-mounted variable-flow repressurization system.

Pump Protection

A low-water-level pump protection switch helps protect the repressurization pump.

Frequently Asked Questions

The system can produce up to 350 gallons per day. Production depends on feed-water temperature and pressure.
The system includes a 16-gallon atmospheric storage tank with a top-mounted variable-flow repressurization system.
Typical TDS rejection is greater than 97%.
The system uses a wall-mounted design.
The water processor is rated at 120V, 60 Hz, and 6W. The repressurization pump is rated at 120V, 60 Hz, and 2A.
A standard Pentair Limited Warranty provides 60 months of coverage for system components and assembly from the date of original shipment, subject to exclusions.
