Ultrafryer Systems (Middleby)

Ultrafryer Systems (Middleby) UltraGold™ B-E20-20-4-UCP Electric Fryer, 4-Vat, 125 lb Each, Stainless Steel, Built-In Filtration

SKU: B-E20-20-4-UCP
$103,979.44
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The UltraGold™ B-E20-20-4-UCP is an electric fryer with four 20-inch vats, each with a 125 lb oil capacity. It features built-in UltraClear Plus filtration, thermostatic controls, and electronic ignition.

The fryer has stainless steel vats, frame, and cabinet, an all-stainless-steel exterior, casters with two brakes, and two baskets per vat. Its total electrical input is 80 kW.

  • Four 20-inch x 20-inch vats
  • 125 lb oil capacity per vat
  • Built-in UltraClear Plus filtration
  • 208 or 240 V operation at 60 Hz

Overall Dimensions:

85.9"W x 39.7"D x 40.82"H

Product Weight:

987.0 lb

Four-vat configuration

Includes four nominal 20-inch x 20-inch vats, each with a 125 lb oil capacity.

UltraClear Plus filtration

Built-in UltraClear Plus filtration is specified for the fryer.

Electric heating

The unit provides 20 kW per vat and 80 kW total electrical input.

Thermostatic controls

Thermostatic controls are specified for the exact model.

Stainless steel construction

The vats, frame, and cabinet are stainless steel, with an all-stainless-steel exterior.

Basket setup

Two baskets are specified per vat.

Caster configuration

The fryer has casters, including two with brakes.

Electronic ignition

Electronic ignition is listed in the authoritative product specifications.

Related Searches

Best Sellers Commercial Fryers Cooking Equipment Electric Fryers Equipment Food Prep Equipment Fryers New Arrivals Restaurant Equipment Ultrafryer Systems (Middleby)
Fuel type Electric
Vat count 4
Nominal vat size 20 in x 20 in
Oil capacity 125 lb per vat
Heating input 20 kW per vat; 80 kW total
Filtration Built-in UltraClear Plus
Controls Thermostatic controls
Ignition Electronic ignition
Basket configuration 2 baskets per vat
Construction Stainless steel vat, frame, and cabinet
Exterior finish All stainless steel exterior
Caster configuration Casters; 2 with brakes
Voltage 208 V or 240 V, 60 Hz
Phase and wiring 3 phase, 3 wire
Current draw 56 A per vat at 208 V; 48 A per vat at 240 V
Control electrical requirements 120 V, 60 Hz, 1 phase, 8.5 A

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Product guide PDF Download PDF Owner's manual PDF Download PDF Middleby financial flyer PDF Download

Frequently Asked Questions

The B-E20-20-4-UCP has four fryer vats.
Each vat has a 125 lb oil capacity.
Yes. The exact model is specified with built-in UltraClear Plus filtration.
The fryer is listed for 208 V or 240 V at 60 Hz with three-phase, three-wire operation. Current is 56 A per vat at 208 V or 48 A per vat at 240 V. The control circuit requires 120 V, 60 Hz, single-phase power at 8.5 A.
Overall dimensions are 85.9 in wide, 39.7 in deep, and 40.82 in high.
Two baskets are specified per vat.
