True Premier Bar TDR84-RI

True Premier Bar TDR84-RI 84-Inch Three-Section Refrigerated Draft Bar Cooler with Flat Top, Self-Contained

$5,509.01
/each
Ships in 15–18 business days
Product type
Refrigerated draft bar cooler
Sections
Three
Door configuration
3 doors
Top style
Flat top
Dimensions
84.0"W × 24.88"D × 34.75"H
Net interior volume
24.94 cu. ft. (706 L)

Questions before you buy?

Talk to an equipment specialist — usually within 1 hour, 9am–6pm EST.

(888) 307-5030 Call Get custom quote

Specifications

Product type Refrigerated draft bar cooler
Sections Three
Door configuration 3 doors
Top style Flat top
Width 84.0 in
Depth 24.88 in; excludes 1.5 in for door handles
Height 34.75 in; excludes 15.75 in for a draft tower and 0.25 in for leg levelers
Net interior volume 24.94 cu. ft. (706 L)
12 oz can capacity 164 six-packs
12 oz bottle capacity 96 six-packs
Half-barrel capacity 3 half-barrels
Shipping dimensions 84 in W x 25 in D x 35 in H
Crated weight 470 lb (214 kg)
Electrical supply 115V/60Hz/1PH
Running load 3.2 A
Electrical connection Cord connected
Cord plug type NEMA 5-15
Cord length 10 ft (3.04 m)
Defrost initiation Automatic
Defrost type Off cycle
Temperature control Digital control
Lighting LED
Refrigerant R290 hydrocarbon
Refrigerant charge 85 g
Factory refrigerator temperature setting 34°F (1.1°C)
Refrigerator temperature range 33°F-38°F (0.5°C-3.3°C)
White wine temperature setting 45°F (7.2°C)
Red wine temperature setting 55°F (12.8°C)
Wine temperature range 42°F-65°F (5.6°C-18.3°C)
Condensing unit location Left side
Expansion device Capillary tube
Pull-out condensing unit Yes
Front vented Yes
Weight 470 lb

Description

The TDR84-RI is an 84-inch, three-section refrigerated draft bar cooler with a flat top and self-contained refrigeration.

  • LED interior lighting
  • R290 hydrocarbon refrigerant
  • Digital temperature control
  • Front-vented, pull-out condensing unit

The listed dimensions are 84.0 inches wide, 24.88 inches deep, and 34.75 inches high. Depth excludes 1.5 inches for door handles, and height excludes 15.75 inches for a draft tower and 0.25 inches for leg levelers.

Overall Dimensions:

84.0"W x 24.88"D x 34.75"H

Product Weight:

470.0 lb

Three-section design

The TDR84-RI is specified as a three-section, three-door model.

Flat top

The unit has a flat-top configuration.

Self-contained refrigeration

Refrigeration is self-contained, with the condensing unit located on the left side.

LED lighting

The refrigerator uses LED lighting.

R290 refrigerant

The refrigeration system uses R290 hydrocarbon refrigerant.

Digital temperature control

Temperature control is digital, with a factory refrigerator setting of 34°F (1.1°C).

Front-vented condensing unit

The condensing unit is pull-out and front vented.

Documentation

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Frequently Asked Questions

The listed dimensions are 84.0 in W x 24.88 in D x 34.75 in H. Depth excludes 1.5 in for door handles, and height excludes 15.75 in for a draft tower and 0.25 in for leg levelers.
Yes. The TDR84-RI uses self-contained refrigeration with a left-side, pull-out condensing unit.
It requires 115V/60Hz/1PH power, is cord connected, and uses a NEMA 5-15 plug with a 10-foot cord.
The unit uses R290 hydrocarbon refrigerant with an 85 g charge.
The net interior volume is 24.94 cu. ft. (706 L). The specification sheet lists capacity for 164 six-packs of 12 oz cans, 96 six-packs of 12 oz bottles, or 3 half-barrels.
The factory refrigerator setting is 34°F (1.1°C), with a refrigerator temperature range of 33°F-38°F (0.5°C-3.3°C).
The warranty statement lists seven-year labor, seven-year parts, and seven-year compressor coverage for covered Premier Bar equipment, subject to its stated conditions and eligibility requirements.
