Traulsen Dealer's Choice UST7230-DD-SB Two-Section 72-Inch Prep Table Refrigerator, 4 Drawers, Holds 30 1/6 Pans

SKU: UST7230-DD-SB
$17,244.00
Discontinued

Want to speak to an expert?

The Traulsen Dealer's Choice UST7230-DD-SB is a two-section, 72-inch prep table refrigerator with four drawers and a low-profile flat cover.

  • The top accommodates 30 1/6-size pans, with 4-inch-deep pans and stainless steel dividers included.
  • The top rails and drawers can accommodate pans up to 6 inches deep.
  • A self-contained, rear-mounted refrigeration system uses R-290 refrigerant and maintains a standard refrigerated-base temperature of 34 to 38°F.
  • The unit includes a reversible white nylon cutting board, insulated stainless steel lift-up pan cover, six 4-inch casters, and an electronic digital control.

Overall Dimensions:

72.0"W x 34.5"D x 36.0"H

30-pan top capacity

The top accommodates 30 1/6-size pans, and 4-inch-deep plastic pans with stainless steel dividers are included.

Four refrigerated drawers

The four drawers accommodate eight 1/6-size pans each and include self-closing and stay-open features.

Self-contained refrigeration

The rear-mounted, front-breathing refrigeration system uses R-290 refrigerant.

Flat cover and cutting board

Includes an insulated stainless steel lift-up pan cover and a reversible white nylon cutting board.

Digital temperature control

An electronic digital controller includes a 3-digit LED display and Fahrenheit or Celsius display capability.

Caster mobility

Includes six 4-inch casters.

Stainless steel construction

The exterior front, top, sides, back, pan lid, and drawers are stainless steel; the bottom is galvanized steel.

Product Type Compact prep table refrigerator
Configuration Two-section
Overall Width 72 in
Overall Depth 34.5 in, including cutting board
Overall Height 36 in on 4 in casters
Drawer Count 4
Top Pan Capacity 30 x 1/6-size pans
Pans per Drawer 8 x 1/6-size pans
Total Pan Capacity 62 x 1/6-size pans
Pan Capacity 4 in deep pans included; accommodates up to 6 in deep pans
Refrigeration Self-contained, rear-mounted, front-breathing
Refrigerant R-290
Operating Temperature 34 to 38°F (1.1 to 3.3°C)
Compressor 1/4 HP
Refrigeration Capacity 1525 BTU/hr
Voltage 115/60/1
Full Load Amperage 7.2 A
Exterior Finish Stainless steel front, top, and sides
Back Finish Stainless steel
Bottom Finish Galvanized steel
Casters Six 4 in casters
Cutting Board 3/4 in reversible white nylon
Power Connection NEMA 5-15P attached plug with 8 ft cord

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

Six-year parts and labor warranty plus a seven-year compressor parts warranty for self-contained models.

Frequently Asked Questions

It accommodates 30 1/6-size pans on top, eight 1/6-size pans per drawer, and 62 1/6-size pans per unit.
Yes. The unit includes its full complement of 4-inch-deep plastic 1/6-size pans and stainless steel pan dividers.
The standard operating temperature is 34 to 38°F (1.1 to 3.3°C).
It uses 115/60/1 power, has a 7.2-amp full-load rating, and includes an attached NEMA 5-15P plug.
Yes. A 3/4-inch-thick, full-length, reversible white nylon cutting board is supplied standard.
