Description
ChekPoint™ Electronic Glass Filler – EC-1210-08-WFK
Hands-free hydration with built-in water filtrationBring touch-free convenience and premium water quality to any countertop. The T&S Brass ChekPoint™ EC-1210-08-WFK combines a sensor-activated glass filler, vandal-resistant 1.5 GPM laminar outlet and an integrated filtration kit—all in one polished chrome, ADA-compliant package that’s ready for quick deck-mount installation.
Key features
- Single-hole deck mount with 8" (203 mm) overall height
- 4 5⁄8" high-arc rigid gooseneck for fast bottle & glass fill-ups
- Infrared sensor activation—no levers to touch or contaminate
- 1.5 GPM vandal-resistant laminar device with anti-microbial coating (Series 6 outlet)
- Water-resistant AC/DC control module
- Runs on included 100-240 VAC adapter or (4) AA batteries
- Dip-switch programming: adjustable auto-time-out, shut-off delay, optional 12-hour auto-flush & metering mode
- Low-battery LED indicator
- Complete water filtration kit
- B-WFK docking station with shut-off lever
- B-WFC replaceable filter cartridge (taste, odor & sediment reduction)
- 20" (508 mm) flexible supply hose – 3⁄8" compression connection
- Lead-free certified, cULus/cCSAus listed & ADA ANSI A117.1 compliant
- Rugged polished chrome-plated brass construction backed by a 3-year limited warranty
At-a-glance specifications
| Manufacturer / Model | T&S Brass – EC-1210-08-WFK |
|---|---|
| Mounting | Single-hole deck mount (Ø 1" / 25 mm) |
| Spout style | 4 5⁄8" high-arc rigid gooseneck |
| Flow rate | 1.5 GPM (5.7 L/min) laminar |
| Power options | 100-240 VAC adapter (included) | (4) AA batteries (not included) | Optional hard-wire transformer |
| Operating pressure | 20 – 125 psi (1.38 – 8.62 bar) |
| Water temperature | 40 – 140 °F (4.4 – 60 °C) |
| Body / Finish | Forged brass with polished chrome plating |
| Certifications | ASME A112.18.1 / CSA B125.1, NSF 61/9 & NSF 372 (low lead), UL 1951, ADA ANSI A117.1, cULus, cCSAus |
| Warranty | 3-Year Limited |
What’s in the box
- ChekPoint™ EC-1210-08 glass filler body & sensor assembly
- Water-resistant control module with built-in flow switches
- 100-240 VAC power adapter (US plug)
- Sensor cable & stainless-steel inlet hoses
- B-WFK filtration kit: docking station, B-WFC filter cartridge & 20" supply hose
- Vandal-resistant key & installation hardware
- Comprehensive installation & programming manual
Need extra capacity? Replacement filter cartridge model EC-FILTER snaps right into the included docking station.
