T&S Brass Wall-Mount Open Stainless Steel Hose Reel Control Unit with 35-Foot Hose

Integrated water control cabinet, high-flow spray gun, and ratcheting retract system

This complete hose reel system combines durable stainless steel construction, integrated water control, and a 35-foot non-marking hose for efficient washdown cleaning.

  • Complete hose reel control unit for commercial washdown applications.
  • Open stainless steel reel includes a 35-foot heavy-duty non-marking hose.
  • Integrated cabinet adds mixing, shut-off, backflow protection, and temperature monitoring.
  • Ratcheting system helps hold hose length in place until a slight tug retracts it automatically.
  • High-flow spray gun with swivel improves reach and handling during cleaning.
  • Wall-mount design includes a multi-fit bracket and connector kit for installation.

Flush-Mount Control Cabinet

Stainless steel water control cabinet with locking latch houses the system components.

Integrated Water Control Components

Includes 1/2 inch union inlets and outlet, 1/2 inch check valves, loose key mixing valve, shut-off valve, and water hammer arrestor.

Backflow Protection

Built with a dual check valve backflow preventer and continuous pressure vacuum breaker.

Bi-Metallic Thermometer

Features a thermometer with a 3-inch dial face for quick temperature checks.

Open Stainless Steel Hose Reel

Open reel construction with 3/8 inch NPT female inlet and a 3/8 inch x 35-foot hose.

Heavy-Duty Non-Marking Hose

Hose is rated to 300 PSI and designed for durability in washdown use.

Ratcheting Retract System

Holds the hose at the desired length until a slight tug releases it for automatic retraction.

High-Flow Spray Gun With Swivel

Spray gun design improves maneuverability and ease of use during cleaning.

Flexible Mounting Hardware

Multi-fit bracket supports wall, ceiling, or under-counter mounting; includes 18-inch riser, 6-inch wall bracket, and adjustable hose bumper.

Type Control Unit and Hose Reel Assembly
Style Open
Installation Type Wall Mounted
Material Stainless Steel
Hose Length 35 Feet
Hose Diameter 3/8 Inch
Water Inlet Size 1/2 Inch
Water Connection Required
Pressure Range 20 to 125 PSI
Pressure Rating 300 PSI
Temperature Range 40 °F to 140 °F
Flow Rate 5.16 GPM @ 60 PSI
Selling Unit Each
Units Per Case 1

Warranty & Protection

One-year limited warranty; hose reel two-year limited warranty.

Documents

PDF Cutsheet PDF Download PDF Submittal PDF Download

Frequently Asked Questions

It includes a 3/8 inch x 35-foot heavy-duty non-marking hose rated to 300 PSI.
The unit is wall-mounted and uses a multi-fit bracket that also supports ceiling or under-counter mounting.
The cabinet includes 1/2 inch union inlets and outlet, check valves, a loose key mixing valve, bi-metallic thermometer, backflow preventer, shut-off valve, and water hammer arrestor.
Operating pressure is 20 to 125 psi, and the temperature range is 40 °F to 140 °F.
The control unit has a one-year limited warranty, and the hose reel has a two-year limited warranty.
Yes. Optional spray valve and wand models listed include B-0107, B-0108, B-0108-H, EB-0107, EB-2322, MV-2516-24, MV-2522-24, and MV-3516-24.
