T&S Brass  |  EasyInstall  |  SKU: B-0137  |  UPC: 671262001250

T&S Brass B-0137 EasyInstall Commercial Faucets & Plumbing

$1,030.42
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Installation and maintenance instructions Submittal
Related Searches
Faucet Components Pre-rinse Faucet Parts Restaurant Equipment Restaurant Equipment Parts

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

EasyInstall™ Pre-Rinse Unit

Model B-0137 | T&S Brass

Built for speed, built to last. The EasyInstall™ Pre-Rinse Unit combines water-saving performance with the legendary durability of T&S Brass, making it the smart choice for busy commercial kitchens looking to cut utility costs without sacrificing power.

Key Features

  • Ultra-efficient 0.65 GPM B-0107-C spray valve delivers WaterSense-certified performance.
  • 8 “ wall-mount mixing faucet with adjustable centers (7 ¾ – 8 ¼”) for fast retrofits.
  • Quarter-turn Eterna cartridges with integrated spring checks stop cross-flow and reduce maintenance.
  • Retractable swivel arm parks at 40 ⅛" and extends to a 26 5⁄16" maximum pull-down reach.
  • 20" stainless-steel hose with heat-resistant gray handle & hold-down ring for operator comfort.
  • Lever handles with red/blue indexes offer instant temperature recognition.
  • Polished chrome-plated brass body and chrome-plated metal handles stand up to daily abuse.
  • 6" adjustable wall bracket stabilizes the riser and protects plumbing connections.
  • Ships with the EasyInstall kit for quicker, labor-saving installs.

Technical Specifications

Model / SKU B-0137 (EasyInstall)
Mounting Wall, 8" adjustable centers
Inlet Size ½" NPT female, 2" flanges
Spray Valve B-0107-C — 0.65 GPM @ 60 psi
Cartridges Quarter-turn Eterna compression w/ spring checks
Handles Lever style, color-coded indexes
Hose Length 20" stainless steel
Overall Height 40 ⅛" (1 020 mm)  — normal hanging
Max Reach 26 5⁄16" (669 mm) pull-down
21 15⁄16" (557 mm) overhang
Operating Pressure 20 – 125 psi
Water Temp. 40 °F – 140 °F
Body Material Polished chrome-plated brass
Warranty 3-year limited

Certifications & Compliance

  • ASME A112.18.1 / CSA B125.1
  • NSF/ANSI 61, Section 9 & NSF/ANSI 372 (low-lead)
  • EPA WaterSense
  • 2019 DOE PRSV — Class I
  • EPAct 2005 compliant

Looking for a different flow rate, handle style, or cartridge option? T&S Brass offers a full range of interchangeable parts to tailor the EasyInstall™ to your exact needs.

Features & Specs

Manufacturer

T&S Brass

Brand_name

EasyInstall

Shipping Weight

14.18lbs

Wall or Deck Mount

splash / wall mount

Faucet Centers

8" centers

Valve Type

compression valves

Specifications

EasyInstall Pre-Rinse Unit, wall mount mixing faucet with 8" adjustable centers, quarter tern Eterna cartridges with spring checks, lever handles with color coded indexes, retractable swivel arm assembly (40" high at normal hanging position, 20-15/16" overhang at maximum pull down), 20" flexible stainless steel hose with heat-resistant gray handle & hold down ring, 0.65 GPM low flow spray valve (B-0107-C), 6" adjustable wall bracket, polished chrome-plated brass faucet body, 1/2" NPT female inlets, CDA
