Summit Commercial HC20BBADA 20-In Under-Cabinet Range Hood, ADA Compliant, Convertible, Black, 270 CFM
The Summit Commercial HC20BBADA is a 20-inch under-cabinet range hood with a black finish and convertible operation for ducted or recirculating installation.
- ADA-compliant design supports operation from a wall switch.
- Provides 270 CFM of ventilation with two fan speeds.
- Supports 3-1/4-inch x 10-inch vertical or horizontal exterior venting, or 7-inch round vertical venting; a transition is required for both.
- Includes a combination charcoal and aluminum mesh filter.
- Designed to be hard-wired and uses an incandescent light bulb, which is not included.
Overall Dimensions:
20.0"W x 20.0"D x 5.5"HProduct Weight:
14.0 lbADA-compliant design
The hood can be controlled from a wall switch for improved accessibility and includes a remote terminal block.
Convertible operation
Supports ducted ventilation to the outside or recirculating ventilation.
270 CFM ventilation
The blower provides maximum air movement of 270 CFM.
Flexible venting
Accepts 3-1/4-inch x 10-inch vertical or horizontal exterior venting, or 7-inch round vertical venting; a transition is required for both.
Two fan speeds
Provides two selectable fan speeds.
Combination filter
Uses a combination charcoal and aluminum mesh filter.
Hard-wired installation
Designed to be hard-wired.
Lighting
Uses an incandescent light bulb; the bulb is not included.
Certifications & Compliance
Warranty & Protection
1-year parts and labor warranty.
