Southbend (Middleby) SE36T-TTB Electric Ranges
Description
Southbend SE36T-TTB 36" Heavy-Duty Electric Range w/ TruVection Oven
24" thermostatic griddle • (2) 9" solid hotplates • Stainless steel constructionPower, versatility, and legendary Southbend durability—packed into a single 36-inch footprint. The SE36T-TTB gives chefs a high-performance 24" griddle, two quick-recovery hotplates, and a 7.5 kW TruVection oven that bakes, roasts, and finishes with exceptional consistency.
Why It Belongs on Your Line
- Two cooking zones in one – 24" griddle (150–450 °F) + (2) 9" solid hotplates with 3-heat switch.
- TruVection technology – ½ HP two-speed fan “scrubs” heat evenly across the cavity for fast, uniform results.
- Rugged, all-stainless exterior & oven lining – built for years of heavy commercial use and easy cleanup.
- Grease-management made easy – full-width front & rear troughs feed two large, slide-out drawers.
- 100 % front-serviceable – quick access to controls, wiring, and components keeps downtime to a minimum.
- Certified safe & sanitary – cETLus & ETL-Sanitation listed.
At-a-Glance Specifications
| Model | SE36T-TTB |
|---|---|
| Overall dimensions | 36" W × 38 ½" D × 38 ¼" H (with legs) |
| Cooktop layout | (1) 24" × 24" griddle, (2) 9" round hotplates |
| Griddle controls | Thermostat, 150–450 °F (2 heating sections, 10.6 kW total) |
| Hotplate controls | Individual 3-heat switch – HIGH / MED / LOW / OFF (5.2 kW total) |
| Range-top power | 15.8 kW |
| Oven type | TruVection, forced-air, electric |
| Oven interior | 29" W × 21.5" D × 14" H, porcelain enamel, coved corners |
| Racks / positions | 3 racks included / 5 positions (1 ⅝" spacing) |
| Oven controls | 150–500 °F solid-state thermostat, 60-min timer, two-speed fan, cool-down mode, “ready” light |
| Oven power | 7.5 kW |
| Electrical | 208, 240, or 480 V / 3 ph (field-wired, terminal block; bottom & rear knockouts) |
| Construction | Welded aluminized steel frame; stainless front, sides, top & oven lining |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 1 year parts & labor |
What’s Included
- (3) heavy-duty wire oven racks
- Adjustable 6" stainless steel legs
- Factory-installed 2-hour cook timer (range top)
- Operator’s manual & warranty documentation
Popular Add-Ons (sold separately)
- 480 V, 3-phase factory wiring
- Set of 6 ¼" locking casters
- Extra slide-out oven racks
- Marine edge top & stainless rear panel kits
Intended for commercial use only. Installation on non-quarry tile floors may require additional accessories—consult factory.
