Southbend (Middleby) SE36D-HHH Electric Ranges
Description
Southbend SE36D-HHH 36" Heavy-Duty Electric Range
(3) 12" x 24" Thermostatic Hot Tops • Standard Oven BaseBuilt to tackle the busiest commercial kitchens, the Southbend SE36D-HHH combines three high-powered hot tops with a spacious standard oven in a single, 36"-wide footprint. Heavy-gauge stainless-steel construction, precise thermostatic controls, and front-serviceable design make this range a long-term workhorse for sautéing, braising, simmering, baking and more.
Key Features
- (3) 12" x 24" rectangular hot tops, thermostatically controlled 250 °F – 850 °F, 5.3 kW each
- 6 kW standard oven with thermostat 150 °F – 450 °F and 2-hour audible timer
- Includes (1) slide-out oven rack; 60 lb meat capacity | fits 18" × 26" sheet pan
- Stainless-steel front, sides, top, and oven lining over a welded aluminized-steel frame
- Front & rear grease troughs with large, easy-empty drawers
- Ventilated, hinged control panel for quick service access; individual indicator lights
- 100 % front-serviceable footprint for line-up or island suite installation
- Certified: cETLus & ETL-Sanitation
Heavy-Duty Electric Performance
Formed tubular elements are clamped beneath each hot top for rapid, even heating, while the oven element surrounds a blower fan that “scrubs” heat throughout the cavity to reach 450 °F in just 20 minutes. Independent thermostats let you sear on one section while holding delicate sauces on another, maximizing production without sacrificing control.
Specifications
| Manufacturer / Model | Southbend SE36D-HHH |
|---|---|
| Range Type | 36" electric heavy-duty range with standard oven |
| Overall Dimensions (W × D × H) | 36" × 38 ½" × 38 ¼" (including legs) |
| Hot Tops | (3) 12" × 24" sections, 5.3 kW each, 250 °F – 850 °F thermostats |
| Oven Interior (W × D × H) | Fits 18" × 26" sheet pan | 12 ½" clear height |
| Oven Elements / Temp | 6 kW total | 150 °F – 450 °F |
| Total Connected Load | 21.9 kW, 3-phase (208 V / 240 V / 480 V field-selectable) |
| Ship / Installed Weight | 700 lb / 599 lb |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 1 year parts & labor (commercial use) |
Popular Options & Accessories
- Extra slide-out oven rack(s)
- Set of four 6 ¼" heavy-duty casters
- Marine edge top for seagoing installations
- Stainless-steel rear panel
- 480 V 3-phase factory configuration
For commercial use only. Unit ships without cord and must be hard-wired by a qualified electrician.
