Southbend SE36D-HHB 36" Heavy-Duty Electric Range
2 Round Hotplates • 2 Hot Tops • Standard Oven BaseBuilt for the busiest commercial kitchens, the Southbend SE36D-HHB delivers all-day versatility in a single, 36-inch footprint. From rapid sautéing and high-volume boiling on the surface to consistent baking below, this rugged range is engineered to keep up with any menu.
Key Features
- (2) 12" × 24" solid hot tops, each 5.3 kW, thermostatically controlled 250 °F – 850 °F
- (2) 9" round hotplates, each 2.6 kW, 3-heat switch (High / Medium / Low)
- 6 kW standard deck oven with single slide-out rack (additional positions available)
- Oven temperature range 150 °F – 450 °F; preheats to 450 °F in ≈20 min
- 2-hour reminder timer with audible signal
- Hinged, front-ventilated control panel for 100 % front serviceability
- All-stainless front, sides, top & oven lining over a welded aluminized-steel frame
- cETLus & ETL-Sanitation listed for commercial kitchens
- One-year parts & labor warranty backed by Southbend’s national service network
At-a-Glance Specifications
Model | SE36D-HHB |
---|---|
Overall Dimensions | 36" W × 38.5" D × 38.25" H (914 × 978 × 972 mm) including 6" legs |
Cooking Surface | (2) 12" × 24" hot tops @ 5.3 kW each | (2) 9" round hotplates @ 2.6 kW each |
Oven Type / Capacity | Standard deck oven, 60 lb meat capacity, 12.5" interior clearance, 1 rack included |
Oven Power | 6 kW tubular element encircling blower fan |
Total Connected Load | 21.8 kW |
Electrical Options | 208 V, 240 V or 480 V, 3-phase (field wired; terminal block provided) |
Construction | Stainless steel front, sides, top & oven lining; welded aluminized-steel body |
Certifications | cETLus, ETL-Sanitation |
Warranty | 1-year parts & labor, commercial use |
Ship Weight | ≈660 lb (299 kg) |
What You Can Do
- Sauté, braise, pan-fry and simmer on the precise 9" plates
- High-heat boil, stew or hold stockpots on the solid hot tops
- Roast, bake and reheat consistently in the fully insulated deck oven
Need mobility or rear shielding? Add optional 6-¼" casters or a stainless rear panel at checkout.
