Southbend (Middleby)  |  S-Series  |  SKU: S60CC-4TR

Southbend (Middleby) S60CC-4TR S-Series Gas Ranges

$11,012.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend S-Series 60" Gas Range with 48" Thermostatic Griddle & 2 Open Burners

Model S60CC-4G/T  |  136,000 BTU  |  cCSAus, CSA Flame, CSA Star, NSF

Get the versatility of a full-size griddle, the speed of two high-output open burners, and the convenience of built-in storage— all in just five feet of line space. Southbend’s S-Series is engineered for the daily punishment of busy diners, food trucks, and restaurant kitchens that need rock-solid performance shift after shift.

Why this range belongs in your kitchen

  • 48" thermostatic griddle (right-side) – 1" thick polished steel plate with raised sides and precise snap-action controls for perfect pancakes, burgers, or sauté prep.
  • (2) 28,000 BTU open burners – one-piece, non-clog cast-iron tops covered by Southbend’s lifetime warranty.
  • Dual cabinet bases – aluminized storage compartments keep sheet pans, utensils, and dry goods within arm’s reach; optional doors available at no charge.
  • Heavy-duty construction – stainless steel front, sides, removable shelf, 4" front rail with welded end caps, and 6" adjustable stainless legs.
  • Easy clean-up – two removable crumb drawers below the burners plus lift-off cast-iron grates that accept up to a 14" stock pot.
  • Hinged lower valve panel – fast service access keeps downtime to a minimum.
  • Factory-installed regulator & pressure test point – simplifies installation and start-up.
  • Certified & warrantied – cCSAus / CSA Flame & Star / NSF listed; backed by a 1-year parts & labor warranty.

At-a-glance specs

Cooktop configuration (2) open burners + 48" thermostatic griddle (right)
Total input 136,000 BTU/hr (Natural or LP)
Open burner rating 28,000 BTU each  |  cast-iron, non-clog
Griddle burners (5) × 16,000 BTU steel tube burners
Griddle plate 48" W × 24" D × 1" T polished steel, raised sides
Overall dimensions 60.75" W × 41.75" D × 59.5" H (with 22.5" flue/shelf)
Gas connection 3/4" NPT male (rear, opposite griddle side)
Required inlet pressure Natural 7" W.C. | LP 11" W.C.
Clearance – combustibles 10" sides & rear (when on 6" legs or casters)
Warranty 1 year parts & labor; lifetime on open-top burners

Popular accessories (sold separately)

  • Swivel casters (front locking)
  • Center-opening cabinet doors
  • Quick-disconnect gas hose kits (3 ft, 4 ft, or 5 ft)
  • 10" flue riser
  • Cheesemelter or salamander broiler mounts
Installation note: This appliance is intended for commercial use only. Install under a properly sized ventilation hood and maintain all local code clearances. If casters are used, a suitable restraining device must be installed to protect the gas connection.

Need flexible financing? Ask about Middleby Equipment Financing for low monthly payments.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

S-Series

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

60.75in

Depth

34.0in

Shipping Weight

1075.0lbs

Vent

backriser with hi-shelf

Exterior Finish

stainless steel front & sides

Top

(2) open burners, (1) 48" griddle with thermostats

Plate Thickness

.500" = 1/2"

Control Type

thermostatic controls

Base

(2) cabinets

Specifications

S-Series Restaurant Range, gas, 60", (2) 28,000 BTU open burners, (1) 48" griddle right, thermostatic controls, (2) cabinet bases, removable cast iron grates, (2) crumb drawers & shelf, hinged lower valve panel, stainless steel front, sides, shelf, 4" front rail & 6" adjustable legs, 136,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
