Southbend (Middleby) S60AD-2TL S-Series Gas Ranges
Description
Southbend S-Series 60" Gas Restaurant Range – 6 Burners, 24" Thermostatic Griddle (Left), Convection + Standard Ovens
Model S60AD-2G/T | 286,000 BTU | cCSAus, CSA Flame & Star, NSFBuilt for high-volume kitchens that demand versatility and reliability, the Southbend S-Series 60" range combines blistering open-top power, precise griddling and dual-oven productivity in one compact footprint. Heavy-gauge stainless steel, lifetime-warranted cast-iron burners and snap-action thermostats ensure years of trouble-free service on the busiest cooklines.
Key Features
- Six 28,000 BTU open burners with non-clog cast-iron heads (lifetime warranty)
- Left-hand 24" griddle – ½" polished steel plate, thermostatically controlled 175-550 °F (3 × 16,000 BTU)
- 35,000 BTU convection oven (right) with 5 rack positions & 2 racks
- 35,000 BTU standard oven (left) with 2 rack positions & 1 rack
- Snap-action thermostats for fast recovery in both ovens
- Removable cast-iron grate tops accommodate pots up to 14"
- Dual full-width crumb drawers speed daily clean-up
- 4" deep stainless front rail & 22.5" flue riser with utility shelf
- Hinged lower valve panel for tool-free service access
- 6" adjustable stainless legs (locking swivel casters optional)
Performance Highlights
- Total input : 286,000 BTU/hr (Natural or Propane)
- 3/4" rear gas connection with factory regulator
- 115 V / 5.9 A plug-in connection powers ½ HP convection blower
- Zero side clearance to non-combustible surfaces; 10" to combustibles
Specification Sheet
| Overall width | 60 3⁄4" / 1543 mm |
|---|---|
| Overall depth (to flue) | 41 3⁄4" / 1060 mm |
| Cooking height | 36" / 914 mm |
| Flue height | 57" / 1448 mm |
| Open burners | 6 × 28,000 BTU cast-iron |
| Griddle | 24" W × 24" D × ½" T steel plate, thermostatic |
| Standard oven cavity | 26" W × 26.5" D × 14" H – 1 rack included |
| Convection oven cavity | 26" W × 24" D × 14" H – 2 racks included |
| Total BTU | 286,000 BTU/hr |
| Gas inlet | 3/4" NPT (rear, opposite griddle) |
| Electrical | 115 V / 1-ph / 5.9 A (cord & plug) |
| Legs | 6" stainless, height-adjustable |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1 year parts & labor (factory authorized service) |
What’s in the Box
- (3) oven racks total
- Factory-installed regulator & 22.5" flue riser with stainless shelf
- Installation & operation manual
Need mobility? Add optional locking casters and a ¾" quick-disconnect hose for safe, flexible positioning.
