Southbend (Middleby) S60AA-4TL S-Series Gas Ranges
Southbend (Middleby) S60AA-4TL S-Series Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) S60AA-4TL S-Series Gas Ranges
Description
Southbend S-Series 60" Gas Restaurant Range
2 Open Burners • 48" Thermostatic Griddle (Left) • Double Convection OvensBuilt for demanding commercial kitchens, the Southbend S-Series combines rugged stainless-steel construction, precise thermostatic controls, and a space-saving 60" footprint. Two high-power open burners, a full 48" griddle, and twin convection ovens give you the versatility to sauté, sear, bake, and roast without breaking stride during the rush.
Performance & Construction Highlights
- 206,000 total BTU output for high-volume production
- (2) 28,000 BTU non-clog cast-iron burners with lifetime warranty
- 48" wide, 1" thick polished steel griddle with raised sides and thermostatic control (175 °F – 550 °F)
- (2) 35,000 BTU convection ovens with ½ hp fan motors for fast, even baking
- Snap-action thermostats throughout for rapid recovery and accurate settings
- Removable cast-iron grate tops handle stock pots up to 14"
- Dual one-piece crumb drawers keep the cooking surface clear
- Hinged lower valve panel simplifies routine maintenance
- Stainless steel front, sides, high shelf, & 4" front rail resist corrosion and dents
- 6" adjustable stainless legs for easy leveling on uneven floors
- Factory-installed ¾" rear gas regulator; natural or LP compatible
- Certified: NSF, cCSAus, CSA Flame, CSA Star
Specifications
| Overall Width | 60 3⁄4" |
|---|---|
| Overall Depth | 41 3⁄4" |
| Height (with flue shelf) | 59 1⁄2" |
| Open Burners | 2 × 28,000 BTU |
| Griddle Plate | 48" W, 1" polished steel, thermostatic |
| Griddle BTU | 5 × 16,000 BTU = 80,000 BTU |
| Ovens | 2 convection, 35,000 BTU each (175 °F – 550 °F) |
| Oven Interior (each) | 26" W × 24" D × 14" H, 5-position guides |
| Racks Supplied | 2 per oven (4 total) |
| Total BTU Input | 206,000 BTU |
| Gas Connection | ¾" NPT, rear (opposite griddle side) |
| Electrical | 115 V / 60 Hz / 1-ph, 6′ cord & plug, 5.9 A |
| Warranty | 1-year parts & labor (factory-authorized service) |
Perfect For
- Full-service restaurants & diners
- High-volume quick-service concepts
- Hotel, resort & casino kitchens
- Catering commissaries
Commercial installation required. Maintain a 10" clearance to combustible surfaces when using 6" legs or casters. For best results, place oversize cookware (12" +) on the rear grates.
