Southbend (middleby)

Southbend (middleby) s48ee-2tl s-series gas ranges

SKU: S48EE-2TL
$10,065.00
/each
Discontinued
Want to speak to an expert?

Southbend S-Series 48" Gas Restaurant Range – 4 Burners, 24" Thermostatic Griddle & Double Space-Saver Ovens

Model S48EE-2G/T-L | 230,000 BTU | cCSAus • CSA Flame • CSA Star • NSF

Maximize production without sacrificing floor space. Southbend’s S-Series packs heavy-duty open burners, a precision-controlled griddle, and two independent ovens into one rock-solid, 48-inch platform built for the daily grind of high-volume kitchens.

Highlights

  • Four 28,000 BTU open burners with non-clog, cast-iron heads (lifetime warranty)
  • 24" thermostatic griddle (½" polished steel) mounted on the left side – perfect for breakfast & searing
  • Two space-saver ovens, 35,000 BTU each, snap-action thermostats 175-550 °F
  • Removable cast-iron grates (hold stock pots up to 14") and dual one-piece crumb drawers
  • Hinged lower valve panel for quick, front-of-unit service access
  • Stainless steel front, sides, 4" welded front rail & 22.5" flue riser shelf
  • 6" stainless steel adjustable legs for easy leveling on uneven floors
  • Factory-installed ¾" regulator & rear gas connection

Performance & Specs

Total input 230,000 BTU/hr (Natural or LP)
Open burners 4 × 28,000 BTU
Griddle 24" W, 3 × 16,000 BTU burners, ½" smooth steel, thermostatic control
Ovens 2 space-saver ovens, 35,000 BTU each; 19.5" W × 26.5" D × 14" H cavity
Racks supplied 1 chrome rack per oven (2 total)
Exterior dimensions 48.63" W × 34" D × 59.5" H (to top of flue shelf)
Gas connection ¾" NPT male, rear; min. inlet 7" WC NG / 11" WC LP
Construction Stainless steel front, sides & shelf; cast-iron top grates
Certifications cCSAus, CSA Flame, CSA Star, NSF
Warranty 1-year parts & labor (commercial use)

What’s Included

  • Southbend S-Series 48" gas range
  • 2 chrome oven racks
  • Factory pressure regulator
  • Owner’s manual & warranty packet

Install under a vented hood and allow 10" clearance to combustible walls. This appliance is intended for commercial kitchens only and is not for household use.

Overall Dimensions:

48.63"W x 34.0"D x 59.5"H

Product Weight:

860.0 lb
Manufacturer Southbend (Middleby)
Brand name S-Series
Certifications ["NSF", "cCSAus", "CSA Star", "CSA Flame"]
Height 59.5in
Width 48.63in
Depth 34.0in
Shipping Weight 860.0lbs
Plate Thickness .500" = 1/2"
Exterior Finish stainless steel front & sides
Top (4) open burners, (1) 24" griddle with thermostats
Vent backriser with hi-shelf
Base (2) standard / space saver ovens
Specifications S-Series Restaurant Range, gas, 48", (4) 28,000 BTU open burners, (1) 24" griddle left, thermostatic controls, (2) space saver ovens, snap action thermostat, (4) removable cast iron grate tops & (2) crumb drawers, hinged lower valve panel, includes (1) rack per oven, stainless steel front, sides, removable shelf, 4" front rail & 6" adjustable legs, 230,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
