Southbend (Middleby) S48DC-4G S-Series Gas Ranges
Description
Southbend S-Series 48" Gas Range w/ Full-Width Griddle & Standard Oven
Model S48DC-4G | 115,000 BTU | Natural or LP GasBuilt for the daily demands of busy restaurants, this S-Series range delivers heavy-duty griddle power, accurate oven baking, and convenient storage in one compact 48 inch footprint. Stainless construction, snap-action oven controls, and service-friendly details make it a true workhorse on the cook line.
Why You’ll Love It
- Full-width griddle: 48" W × 24" D, 1" thick polished steel plate with raised splash sides.
- 80,000 BTU griddle output (5 burners @ 16,000 BTU) with manual individual valve controls for quick zone adjustments.
- Standard oven: 35,000 BTU “U”-shaped burner, snap-action thermostat 175–550 °F, 26" W × 26-1/2" D × 14" H cavity, 2-position guides & 1 rack included.
- Aluminized cabinet base keeps sheet pans & smallwares within arm’s reach (optional doors available).
- Dual removable crumb/grease drawers & hinged lower valve panel speed up cleaning and service.
- Stainless steel front, sides, 4" front rail with welded end caps, removable 22-1/2" flue shelf, and 6" adjustable legs.
- Factory-installed 3/4" pressure regulator; field convertible for Natural Gas or LP.
- Certified cCSAus, CSA Flame, CSA Star & NSF for commercial kitchens.
- Backed by a 1-year parts & labor warranty from Southbend.
Technical Specifications
| Overall Dimensions (W × D × H) | 48-5/8" × 34" × 59-1/2" (to top of flue shelf) |
|---|---|
| Griddle Plate | 48" W × 24" D, 1" thick polished steel |
| Griddle Output | 80,000 BTU (5 burners @ 16,000 BTU) |
| Oven Type / Output | Standard, snap-action | 35,000 BTU |
| Oven Interior (W × D × H) | 26" × 26-1/2" × 14" |
| Total Gas Input | 115,000 BTU/hr |
| Gas Connection | 3/4" NPT rear • 7" W.C. NG • 11" W.C. LP |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year parts & labor |
Popular Accessories (sold separately)
- Swivel casters (front pair locking)
- Center-opening cabinet doors (no-charge option)
- Extra oven racks
- 10" flue riser
- Quick-disconnect gas hose & restraining device (3 ft, 4 ft, or 5 ft)
- Cheesemelter or salamander broiler mounts
