Southbend (Middleby) S48DC-3TL S-Series Gas Ranges
Description
Southbend S-Series 48" Gas Restaurant Range
Model S48DC-3G/T – 2 Open Burners • 36" Thermostatic Griddle (Left) • Standard Oven • Cabinet BaseBring big-kitchen performance to the line with Southbend’s compact, 48-inch S-Series range. A pair of 28,000 BTU open burners, a full 36-inch thermostatic griddle, and a high-capacity standard oven give your team the flexibility to sauté, sear, grill, and bake from a single footprint—while the integrated cabinet keeps sheet pans and smallwares right where you need them.
Top-Line Features
- 2 × 28,000 BTU open burners with lifetime-warranty, one-piece cast-iron heads
- 36" smooth, polished ½" steel griddle (left-hand) with snap-action thermostatic controls (175 °F-550 °F)
- 35,000 BTU standard oven with U-shaped burner, enamel interior & 2-position rack guides (1 rack included)
- Convenient cabinet base (door-ready, opens from center) for dry storage
- Individual, removable cast-iron grate tops & two crumb drawers for fast cleanup
- Hinged lower valve panel and factory-installed pressure regulator simplify service
- Durable stainless-steel front, sides, 4" front rail, removable high-shelf & 6" adjustable legs
Performance at a Glance
- Total input: 155,000 BTU/hr
- Open burners: 56,000 BTU (2 × 28 k)
- Griddle: 64,000 BTU (4 × 16 k)
- Oven: 35,000 BTU
Technical Specifications
| Overall width | 48 ⅝" |
|---|---|
| Depth (incl. handles) | 34" |
| Height w/ 22.5" flue shelf | 59.5" |
| Cooking surface height | 37" |
| Oven interior (W × D × H) | 26" × 26.5" × 14" |
| Gas type | Natural or LP (field convertible) |
| Gas connection | ¾" NPT, rear (opposite griddle side) |
| Minimum inlet pressure | Nat 7" WC / LP 11" WC |
| Shipping weight | Approx. 860 lb |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
Popular Options & Accessories
- Swivel casters (front locking)
- Cabinet doors (no-charge option)
- Extra oven racks
- 10" flue riser or salamander / cheese melter mounting kits
- ¾" quick-disconnect gas hose assemblies (3 ft, 4 ft, 5 ft)
Peace-of-Mind Warranty
Backed by Southbend’s 1-year parts & labor warranty and nationwide network of authorized service agencies.
Intended for commercial use only. Install under a properly sized vent hood and consult local codes for clearance and utility requirements.
