Southbend (Middleby) S36C-3G S-Series Gas Ranges
Description
Southbend S-Series 36" Gas Griddle Range w/ Cabinet Base
Model S36C-3G/T • 64,000 BTU • cCSAus, CSA Flame, CSA Star, NSFBuilt for busy commercial kitchens that need a single, heavy-duty workhorse, the Southbend S-Series 36" Griddle Range delivers high heat, rock-solid construction, and convenient under-counter storage—all in a compact 36½-inch footprint.
Why You’ll Love It
- Full-width 36" griddle with a ½" thick, polished steel plate for fast recovery and even heat.
- Four independently controlled 16,000 BTU burners (64,000 BTU total) let you create up to four cooking zones.
- Manual control valves—ideal for chefs who prefer direct flame adjustment over thermostats.
- Stainless steel front, sides, 22½" flue riser and removable high-shelf stand up to daily abuse.
- 4" deep stainless front rail with welded end caps keeps pans & plates safely in place.
- 6" stainless steel legs adjust for a level work surface on uneven floors.
- Aluminized cabinet base (no oven) adds dry storage right where you need it; optional swing-out doors available at no charge.
- Simple rear ¾" NPT gas connection with factory-installed pressure regulator.
- Certified for commercial use: cCSAus, CSA Flame, CSA Star & NSF.
Performance You Can Count On
- 1/2" steel plate retains heat for quick searing while minimizing temperature drop during peak periods.
- Raised side & back splashes help contain grease; large front grease drawer slides out for speedy clean-up.
- Heavy-duty metal control knobs with a red alignment stripe resist heat & impact.
- Hinged lower valve panel provides instant service access without removing the griddle plate.
Specifications
| Cooking Surface | 36" W x 21" D (full-width griddle) |
|---|---|
| Total BTU Input | 64,000 BTU (4 × 16,000 BTU) |
| Plate Thickness | ½" polished steel |
| Overall Width | 36.5" |
| Overall Depth | 34" |
| Overall Height | 59.5" (to top of shelf) • 37" to griddle surface |
| Base Type | Open cabinet, aluminized; optional doors (no charge) |
| Gas Connection | ¾" NPT male, rear |
| Required Gas Pressure | Natural Gas – 7" W.C. | LP – 11" W.C. |
| Clearances* | 0" sides/back to non-combustible • 10" to combustible |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1 year parts & labor (commercial use) |
Popular Factory Options (Sold Separately)
- Heavy-duty swivel casters (front set locking)
- Center-opening cabinet doors
- 10" flue riser (low-profile installations)
- ¾" quick-disconnect gas hose kits (3', 4', or 5')
*Clearances shown apply when unit is installed on 6" legs or casters. Install under a properly sized vent hood and follow all local codes for gas & fire safety. Intended for commercial use only.
