Southbend (middleby)

Southbend (middleby) s36c-2tl s-series gas ranges

SKU: S36C-2TL
$5,012.00
/each
Discontinued
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

New arrivals Southbend (middleby)

Southbend S-Series 36" Gas Range w/ 24" Thermostatic Griddle & Cabinet Base – Model S36C-2G/T

104,000 BTU | 2 Open Burners + 24" Griddle (Left) | cCSAus, CSA Flame, CSA Star, NSF

Built for busy kitchens that need rock-solid durability and versatile cooking zones in a compact footprint, the Southbend S-Series S36C-2G/T pairs two 28,000 BTU open burners with a high-output 24" thermostatic griddle and roomy cabinet base storage. 100 years of Southbend engineering are packed into a fully stainless exterior that’s ready for the daily rush.

Why Choose the S36C-2G/T

  • Dual 28,000 BTU non-clog cast-iron burners (lifetime warranty) for rapid sautéing & stock-pot capacity up to 14".
  • 24" polished ½" thick steel griddle (left-side) heated by three 16,000 BTU burners with precise thermostatic control for breakfast classics, smash burgers or tortillas.
  • Independent removable cast-iron grates and one-piece crumb drawer make clean-up fast.
  • Aluminized cabinet base offers dry, ventilated storage; optional center-opening doors available at no charge.
  • Rugged stainless-steel front, sides, 4" front rail and 22.5" flue-riser shelf stand up to daily abuse.
  • Hinged lower valve panel and factory-installed regulator for quick service access.
  • 6" stainless adjustable legs—install on combustible floors with required 10" rear clearance.

Technical Specs

Gas Type Natural (field-convertible to LP)
Total Input 104,000 BTU/hr
(56,000 BTU open top • 48,000 BTU griddle)
Controls Manual valves (burners) • Snap-action thermostats 175-550 °F (griddle)
Cooking Surface Height 37"
Overall Dimensions 36.5" W × 34" D × 59.5" H (to top of flue shelf)
Gas Connection ¾" NPT male, rear (opposite side of griddle)
Minimum Inlet Pressure 7" W.C. Natural • 11" W.C. LP
Shipping Weight Approx. 535 lb
Certifications cCSAus • CSA Flame • CSA Star • NSF
Warranty 1-year parts & labor; lifetime warranty on open burners

Included

  • 22.5" stainless flue riser with single storage shelf
  • Factory-installed pressure regulator
  • Set of 6" stainless adjustable legs

Popular Accessories (Sold Separately)

  • All-swivel locking casters
  • Center-opening cabinet doors (no-charge option when specified)
  • 3 ft / 4 ft / 5 ft ¾" quick-disconnect hose with restraining device (ANSI Z21.69)
  • Shelf-mounted salamander or cheesemelter kits
Commercial Use Only: For installation on combustible floors maintain 10" clearance at rear and sides. To avoid premature component damage, do not allow cookware larger than 12" Ø to overhang the front rail.

Need flexible financing? Middleby Equipment Financing can turn this range into an affordable fixed monthly payment—ask your rep for details.

Overall Dimensions:

36.5"W x 34.0"D x 59.5"H

Product Weight:

660.0 lb
Manufacturer Southbend (Middleby)
Brand name S-Series
Certifications ["NSF", "cCSAus", "CSA Star", "CSA Flame"]
Height 59.5in
Width 36.5in
Depth 34.0in
Shipping Weight 660.0lbs
Vent backriser with hi-shelf
Exterior Finish stainless steel front & sides
Plate Thickness .500" = 1/2"
Base (1) cabinet
Top (2) open burners, (1) 24" griddle with thermostats
Specifications S-Series Restaurant Range, gas, 36", (2) 28,000 BTU open burners, (1) 24" griddle left, thermostatic controls, (1) cabinet base, removable cast iron grate tops & crumb drawer, hinged lower valve panel, stainless steel front, sides, shelf, 4" front rail & 6" adjustable legs, 104,000 BTU, cCSAus, CSA Flame, CSA Star, NSF

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download
