Southbend (Middleby) S36A-3G S-Series Gas Ranges
Description
Southbend S-Series 36" Full-Griddle Gas Range w/ Convection Oven
Model S36A-3G/T • SKU 7707Built to keep up with the busiest kitchens, the 36" Southbend S-Series combines a high-output griddle and a space-saving convection oven in one rugged, all-stainless package. Enjoy 99,000 BTU of cooking power, precision snap-action controls, and legendary Southbend durability.
Why You’ll Love It
- All-Griddle Top – 36" of ½"-thick polished steel with raised sides for fast, even heat transfer and easy cleanup.
- Four 16,000 BTU Burners under the plate deliver 64,000 BTU total and let you create independent cooking zones.
- Space-Saver Convection Oven (35,000 BTU) with snap-action thermostat (175 °F – 550 °F) and ½ HP blower for quick, even baking or roasting.
- Five-position rack system ships with two chrome racks so you can load pans exactly where you need them.
- Built for Commercial Duty – stainless steel front, sides, 22.5" high flue-shelf, 4" rail with welded end caps, and 6" adjustable legs.
- Removable cast-iron grates, one-piece crumb drawer, and hinged lower valve panel speed up daily maintenance.
- Plug-and-Cook – factory regulator, ¾" rear gas connection, plus a 115 V cord & plug (5.9 A) for the convection fan.
- Certified & Warranty-backed – cCSAus, CSA Flame, CSA Star & NSF listed with 1-year parts & labor warranty.
Technical Specifications
| Overall width | 36.5" (927 mm) |
|---|---|
| Overall depth (with handle) | 41.75" (1,060 mm) |
| Cook surface height | 37" |
| Griddle plate | Polished steel, ½" thick, 36" W |
| Griddle input | 64,000 BTU/hr (4 × 16,000 BTU) |
| Oven type | Gas convection, space-saver |
| Oven input | 35,000 BTU/hr |
| Oven interior (W × D × H) | 26" × 24" × 14" |
| Temperature range | 175 °F – 550 °F |
| Racks / guides | 2 racks standard / 5 positions |
| Total gas input | 99,000 BTU/hr |
| Gas connection | ¾" NPT (rear) |
| Electrical | 115 V, 60 Hz, 1-ph, 5.9 amps, cord & NEMA plug |
| Adjustable legs | 6" stainless steel |
| Ship weight | ≈ 535 lb (243 kg) |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
Popular Factory Options
- Swivel casters (front locking)
- Restraining device & quick-disconnect hose (3 ft, 4 ft or 5 ft)
- Extra oven racks
- 10" flue riser for salamander or cheesemelter mounts
Warranty & Support
One-year parts & labor warranty when installed and serviced by a Southbend Authorized Service Agency. Extended coverage available via Middleby Finance.
