Southbend (Middleby)  |  Platinum  |  SKU: PE36N-BBB

Southbend (Middleby) PE36N-BBB Platinum Electric Ranges

$9,461.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Warranty sheet
Related Searches
Commercial Ranges Electric Ranges Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Platinum Series 36" Modular Electric Heavy-Duty Range

6 Solid Round Hotplates • Model PE36N-BBB • cCSAus & NSF Listed

Engineered for relentless, round-the-clock service, Southbend’s Platinum Series PE36N-BBB packs six high-performance hotplates into a compact 36-inch footprint. Each 9-inch solid element delivers a full 2.6 kW of power, giving your kitchen 15.6 kW of instant, even heat with the rock-solid durability demanded by today’s busiest operations.

Key Features

  • Six 9" solid round hotplates, 2.6 kW each (15.6 kW total).
  • Individual 4-position switches – High / Medium / Low / Off – for fast, repeatable control.
  • Modular design drops onto a countertop, refrigerated or freezer base for maximum layout flexibility.
  • Rugged all-stainless exterior plus fully insulated burner box for superior thermal efficiency.
  • 9-1/4" deep stainless steel front rail doubles as a sturdy plating shelf.
  • 5" stainless flue riser directs heat toward the ventilation hood.
  • 6" adjustable stainless steel legs level the unit on uneven floors.
  • Certified cCSAus & NSF; built in the USA and backed by a 1-year parts & labor warranty.

Specifications

Model PE36N-BBB (Modular Mount)
Cooking Surface 6 × 9" solid round hotplates
Output 2.6 kW per plate  |  15.6 kW total
Controls 4-position switch on each plate – High / Medium / Low / Off
Overall Dimensions (W × D × H*) 36" × 37-1/2" × 43-1/2"
*Height includes 6" legs and 5" flue riser
Electrical 208 V / 240 V / 480 V, 3-phase, 15.6 kW
208 V – 43.4 A per line  |  240 V – 37.6 A  |  480 V – 18.8 A
Front Rail Depth 9-1/4"
Legs 6" stainless steel, adjustable
Construction Stainless steel front, sides, rear & bottom; fully insulated
Certifications cCSAus, NSF
Warranty 1-year limited parts & labor

Ideal For

  • High-volume restaurants, hotels & catering facilities
  • Commissaries & ghost kitchens with all-electric lineups
  • Institutional foodservice – schools, hospitals & correctional facilities
  • Any operation demanding heavy-duty, reliable cooktop performance
Important: For commercial use only. Install under a properly sized ventilation hood and observe minimum clearances per local code. Avoid cookware over 12" in diameter from overhanging the front rail to prevent heat damage.

Need a matching refrigerated base, extra-deep flue riser or other accessories? Contact us for custom Southbend battery configurations.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Platinum

Certifications

NSF, cCSAus

Height

13.5in

Width

36.0in

Depth

37.5in

Exterior Finish

all stainless steel exterior

Base

modular (no base)

Top

(6) hotplates / french plates

Specifications

Platinum Heavy Duty Range, electric, 36", modular, (6) round hotplates, 2.6 kW per plate, thermostatic controls, front rail, stainless steel construction, 6" adjustable legs, cCSAus, NSF
