Southbend (Middleby) PE36C-HHH Platinum Electric Ranges
Description
Southbend Platinum Series 36" Electric Heavy-Duty Range
Model PE36C-HHH – Cabinet-Base, Three Thermostatic Hot PlatesBuilt for relentless commercial use, the Southbend Platinum 36" electric range delivers 15.9 kW of precise, evenly distributed heat across three expansive 12" × 24" hot plates—giving high-volume kitchens the speed, control and durability they demand.
Why You’ll Love It
- Three 5.3 kW stainless-steel hot plates (12" × 24" each) handle stockpots, skillets and oversized cookware with ease.
- Independent thermostatic controls maintain surface temperatures from 250 °F – 850 °F.
- ½"-thick continuous plate ensures quick recovery and uniform heat distribution.
- 9¼" deep front rail keeps tools close and operators protected from radiant heat.
- Removable stainless-steel grease drawer makes end-of-shift cleanup fast and simple.
- Fully insulated burner box and 5" flue riser improve efficiency and cook-line comfort.
- All-stainless exterior (front, sides, rear & bottom) stands up to harsh kitchen environments.
- Cabinet base with center-opening doors offers convenient, ventilated storage.
- 6" adjustable stainless legs allow perfect leveling on uneven floors.
- cCSAus & NSF listed for safety and sanitation compliance.
Engineered for the Line
Part of Southbend’s heavy-duty sectional platform, this range can be installed as a stand-alone workhorse or batteried with other Platinum modules to create a custom cook suite tailored to your menu.
Specifications
| Cooking Surface | (3) Hot plates, 12" × 24" each, ½" thick |
|---|---|
| Heat Source | Electric, 5.3 kW per plate (15.9 kW total) |
| Temperature Range | 250 °F – 850 °F (thermostatic) |
| Overall Width | 36" / 914 mm |
| Depth (front → back) | 37½" / 953 mm |
| Height (to cook surface) | 36" / 914 mm | +5" flue riser |
| Base | Stainless cabinet with removable center-opening doors |
| Legs | 6" stainless, height-adjustable |
| Electrical | 208 V / 240 V / 480 V, 3-phase, 15.6 – 15.9 kW (≈ 43 A/line @ 208 V) |
| Shipping Weight | ≈ 600 lb / 272 kg |
| Certifications | cCSAus, NSF |
| Warranty | 1-year parts & labor (commercial use) |
Perfect For
- Hotels and institutions needing continuous, high-capacity production
- Independent restaurants seeking greater station throughput and precise heat control
- Commissaries and caterers building custom battery line-ups
What’s in the Box
- Factory-installed 5" stainless flue riser
- Removable grease drawer
- Installation & operation manual
- Southbend Platinum Series limited warranty
Upgrade your cook line with the unyielding power and precision of Southbend’s Platinum Series—designed to keep you cooking shift after shift.
