Southbend (Middleby) PE24C-HH Platinum Electric Ranges
$8,506.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Southbend (Middleby) PE24C-HH Platinum Electric Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) PE24C-HH Platinum Electric Ranges
$8,506.00
Unit price
/
Unavailable
Description
Southbend Platinum 24" Electric Heavy-Duty Range – 2 Hotplates & Cabinet Base
Model PE24C-HH | cCSAus & NSF ListedTackle demanding production volumes in a tight footprint with the Platinum Series PE24C-HH. Twin 12" × 24" solid hot plates deliver a combined 10.6 kW of searing power, while the heavy-gauge stainless cabinet base gives you rugged storage right on the cook line.
Performance & Construction Highlights
- Two 12" × 24" thermostatically controlled hot plates – 5.3 kW each
- Surface temperature range: 250 °F – 850 °F (121 °C – 454 °C)
- ½" thick steel cooking surface ensures even heat distribution & recovery
- Independent control knobs for precise multi-zone cooking
- 9¼" deep stainless front rail doubles as plating/prep shelf
- Fully insulated burner box keeps kitchen cooler & saves energy
- Removable stainless grease drawer for quick, mess-free cleanup
- Stainless cabinet base with center-opening removable doors
- 5" stainless flue riser directs heat into the hood
- 6" adjustable stainless legs for easy leveling
Specification Overview
| Cook Surface | (2) 12" × 24" solid tops, ½" thick |
|---|---|
| Total Output | 10.6 kW (240/480 V) / 10.4 kW (208 V) |
| Temperature Range | 250 °F – 850 °F |
| Controls | Independent thermostatic dials |
| Exterior Dimensions | 24" W × 40" D × 37.5" H (to top of 5" flue) |
| Electrical | 208, 240, or 480 VAC, 3-phase (43.4 / 38.3 / 19.2 A) |
| Shipping Weight | 349 lb (158 kg) |
| Certifications | cCSAus, NSF |
| Warranty | 1-year limited parts & labor |
Important: For maximum longevity, place oversized cookware (12" diameter or larger)
toward the rear of the plates to prevent excess heat build-up on the front rail.
Need flexible payments? Ask your rep about quick, fixed-rate Middleby Equipment Financing.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Platinum
Certifications
NSF, cCSAus
Height
41.0in
Width
24.0in
Depth
37.5in
Exterior Finish
stainless steel front & sides
Top
(2) hotplates
Base
cabinet base(s)
Specifications
Platinum Heavy Duty Range, electric, 24", (2) 12" x 24" hotplates, 5.3 kW per plate, thermostatic controls, front rail, cabinet base with removable door, stainless steel construction, 6" adjustable legs, cCSAus, NSF
