Southbend (Middleby) PE12C-H Platinum Electric Ranges

Southbend Platinum Series 12" Electric Heavy-Duty Range – Model PE12C-H

Engineered for the busiest commercial kitchens, the Southbend Platinum PE12C-H delivers intense, even heat from a 5.3 kW hot top while giving you the rugged construction, flexibility, and storage space you need to build the perfect cookline.

Why It Belongs in Your Kitchen

• 12" x 24" hot plate with a ½" thick steel surface for superior heat retention and recovery.
• 5.3 kW element & thermostatic control – set surface temperatures anywhere from 250 °F to 850 °F with a single, precise knob.
• Heavy-duty stainless steel front, sides, rear, and exterior bottom stand up to daily abuse and simplify cleanup.
• 9-¼" deep front rail keeps cookware off the controls and doubles as a plating shelf.
• Removable stainless grease drawer makes end-of-shift maintenance fast and sanitary.
• Fully insulated burner box increases efficiency and keeps your kitchen cooler.
• Cabinet base with center-opening, removable doors provides dry storage for pans, utensils, or chemicals.
• 5" flue riser + 6" adjustable legs for proper ventilation and easy leveling on uneven floors.
• Sectional design integrates seamlessly into a Platinum battery or works great as a stand-alone unit.
• Certified cCSAus & NSF for gas/electric safety and sanitation.

Specifications

*Unit ships from factory wired for 3-phase. Field conversion is not recommended. Always verify local codes prior to installation.

Installation & Operating Tips

• Minimum clearance from combustible construction: 10" sides, 12" rear.
• Install under a properly vented hood for optimum performance.
• Limit oversized cookware (12"+ diameter) to the rear half of the plate to avoid excess heat on the front rail.
