Southbend (Middleby) PE12C-B Platinum Electric Ranges
Description
Platinum 12" Heavy-Duty Electric Range, 2 Hot Plates
Southbend Model PE12C-B | 5.2 kW total output | cCSAus & NSF ListedBuilt to anchor the busiest cooklines in a footprint barely wider than a sheet pan, the Southbend Platinum PE12C-B delivers hard-hitting performance, rugged 430/304 stainless-steel construction and the flexibility of a fully enclosed cabinet base.
Why Choose This Range
- Two powerful 9" solid round hot plates (2.6 kW each) for fast, even heating.
- 4-position switch (Off / Low / Medium / High) on each plate for simple, repeatable control.
- 9-1/4" deep front rail keeps pans stable and operators safe.
- Fully insulated burner box boosts efficiency and keeps sides cool to the touch.
- Stainless steel cabinet base with center-opening removable doors—ideal for pan, utensil or dry-goods storage.
- 5" stainless flue riser directs heat and vapors into the hood, protecting the cookline.
- 6" adjustable stainless legs for easy leveling and simple floor cleaning.
- Battery-ready front manifold allows seamless line-up with other Southbend Platinum units.
Technical Specifications
| Cooking surface | (2) 9" solid round hot plates |
|---|---|
| Output | 2.6 kW per plate | 5.2 kW total |
| Control type | 4-position selector (High / Medium / Low / Off) |
| Voltage options | 208, 240 or 480 VAC | 3-phase, 50/60 Hz |
| Max amp draw | 21.7 A @ 208 V | 18.8 A @ 240 V | 9.4 A @ 480 V |
| Dimensions (W × D × H) | 12" × 37-1/2" × 36" to cook surface (41" overall with standard 5" flue riser) |
| Shipping weight | ≈ 200 lb (91 kg) |
| Base | Stainless cabinet, removable double doors |
| Legs | (4) 6" adjustable stainless legs |
| Certifications | cCSAus, NSF |
| Warranty | 1-year parts & labor (commercial use) |
Popular Options (sold separately)
- 24" or 36" flue riser with single or double shelves
- Casters (front two locking) with cable restraint kit
- Open-frame base with casters for battery installations
- Tray or tubular side shelves (12" deep)
- Extra-deep rear-extending flue riser
