Southbend (Middleby) PCE15S/TD-V Platinum Convection Ovens
Description
Southbend Platinum Ventless Double Convection Oven – Touchscreen, 7.5 kW/Deck
Model PCE15S/T | CSA • NSF • ENERGY STAR®Put powerful, ENERGY STAR®-qualified baking anywhere on your line—no hood required.* The Platinum ventless double deck from Southbend couples two 7.5 kW standard-depth ovens with an intuitive touchscreen and rugged stainless-steel construction, all in a 64.8 in-tall footprint.
Why you’ll love it
- Ventless internal catalyst captures grease & smoke for hood-free installation*
- Full-color Touchscreen stores recipes, runs individual rack timers and holds product at 140–200 °F
- Patented “plug-in / plug-out” control module slides out the front for fast, no-tools service
- 180° dependent glass doors with dual seals retain heat and let staff monitor bakes at a glance
- 11-position guides & 5 heavy-duty racks per cavity = up to 10 full-size sheet pans at once
- Two-speed ½ HP fan delivers even, edge-to-edge browning; forced cool-down protects components
- Coved, fastener-free porcelain enamel interior wipes clean in seconds
- All-stainless front, sides & top with stay-cool door handles built for demanding kitchens
At-a-glance specs
| Manufacturer / Series | Southbend – Platinum |
|---|---|
| Model | PCE15S/T • Double deck • Touchscreen • Ventless |
| Heat source | Electric – 7.5 kW per deck (15 kW total) |
| Temperature range | 150–550 °F cook / 140–200 °F hold |
| Decks / Capacity | 2 decks • 11 rack positions / 5 racks per deck |
| Interior size (W×D×H) | 29" × 21.5" × 20" (737 × 546 × 508 mm) |
| Exterior size (W×D×H) | 40.6" × 37.25" × 64.8" (1032 × 946 × 1645 mm) with 6" legs |
| Fan motor | ½ HP, two-speed (1710 / 1120 RPM) |
| Electrical | 208, 240, 380, 415 or 480 VAC • Single or 3-phase |
| Certifications | CSA, NSF, ENERGY STAR® |
| Warranty | 1-year parts & labor |
| Shipping weight | ≈ 1,040 lb (472 kg) |
Typical amperage – 7.5 kW elements
| Voltage | Phases | Amps / Line |
|---|---|---|
| 208 V / 60 Hz | 1-phase | 36.1 A |
| 208 V / 60 Hz | 3-phase | 20.9 A |
| 240 V / 60 Hz | 1-phase | 31.3 A |
| 240 V / 60 Hz | 3-phase | 18.1 A |
| 480 V / 60 Hz | 3-phase | 9.1 A |
Add up to 4.3 A for the control module. Always confirm field requirements with a licensed electrician.
What’s in the box
- (10) Nickel-plated heavy-duty oven racks
- 6" stainless adjustable legs
- Interior lighting – 2 bulbs per deck
- Installation & operation manuals
Popular add-ons (sold separately)
- 4" or 6" heavy-duty casters
- Marine-edge top or stainless steel bottom panels
- Independent or solid stainless doors
- Export crating for overseas shipment
*Intended for commercial use only.
