Southbend (Middleby) PCE15B/TD-V Platinum Convection Ovens
Description
Southbend Platinum Series Double Convection Oven – Ventless, 7.5 kW/Deck
Model PCE15B/T (Bakery-Depth, Touchscreen Controls)Built for high-volume, high-precision baking, the Platinum Series double deck convection oven delivers even, consistent results in a compact 43½ in. footprint. Each deck is powered by a high-efficiency 7.5 kW heating system and a two-speed fan that “scrubs” heat across every rack, while Southbend’s new UL-certified ventless catalyst lets you take your bake anywhere—no dedicated hood required.*
Key features
- Touchscreen control with Manual, Recipe & Rack modes (150 – 550 °F + 140 – 200 °F hold)
- 7.5 kW high-efficiency heating elements per deck (15 kW total)
- Ventless internal catalytic converter – install without a Type I hood*
- Dependent low-emission glass doors open a full 180° for unobstructed loading
- 11-position rack guides & 5 plated racks included
- 1⁄2 hp, 2-speed fan motor with forced cool-down mode
- Stainless steel front, sides & top with stay-cool handles
- Plug-in / slide-out control panel for fast, front-service access
- Coved, fastener-free porcelain enamel interior with dual halogen lights
- 1-year parts & labor warranty backed by Southbend’s nationwide service network
Specification highlights
| External dimensions (W × D × H) | 43.5 in × 36.5 in × 64.8 in (1105 × 927 × 1646 mm) |
|---|---|
| Interior dimensions (per deck) | 29 in W × 29 in D × 20 in H (737 × 737 × 508 mm) |
| Heating elements | 7.5 kW tubular sheath elements per deck |
| Electrical | 208–480 V, 1- or 3-phase field configurable (add 4.3 A for control circuit) |
| Fan motor | ½ hp, 2-speed (1710 / 1120 RPM) |
| Oven racks | 5 chrome-plated racks, 11 positions on 1⅝ in centers |
| Shipping weight | ≈ 1180 lb (535 kg) |
| Clearances | 0″ front & right, 2″ left & rear (non-combustible) |
Why go Ventless?
- Eliminates costly hood installation & ductwork
- Allows flexible placement in kiosks, cafés, schools & historic buildings
- Catalyst captures grease-laden vapors and neutralizes smoke before discharge
*Ventless certification applies only when factory-installed catalytic system is selected. For standard (non-ventless) models, Southbend recommends installation under a properly sized Type I hood.
