Southbend (Middleby)  |  Platinum  |  SKU: P48A-BBBB

Southbend (Middleby) P48A-BBBB Platinum Gas Ranges

$20,177.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Gas Ranges Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Platinum 48" Heavy-Duty Gas Range with 8 Open Burners & Convection Oven

Model P48A-BBBB • 325,000 BTU • CSA & NSF Listed

Built for the rigors of high-volume kitchens, Southbend’s Platinum Series 48" range combines blistering cook-top power with a high-performance convection oven and handy base storage—all wrapped in a fully stainless chassis that’s ready for years of punishing service.

Key Features
  • Eight patented clog-free open burners rated at 35,000 BTU each (280,000 BTU total).
  • Manual infinite valves deliver quick, precise flame control from gentle simmer to rolling boil.
  • Removable, welded-steel top grates for effortless cleaning and maximum durability.
  • Integrated 45,000 BTU convection oven:
    • Porcelain-enamel interior resists corrosion and wipes clean.
    • Three adjustable racks, five position rails.
    • 175 °F – 550 °F “Insta-On” thermostat.
    • 1/2 HP two-speed blower for consistent, even baking.
  • 12" right-hand stainless-steel cabinet keeps sheet pans, smallwares or spices within arm’s reach.
  • 9-1/4" deep front rail doubles as a plating/landing ledge.
  • 5" stainless flue riser funnels heat toward the hood, keeping the cook-line cool.
  • 6" adjustable stainless legs for easy leveling and thorough floor cleaning.
  • 1-1/4" front gas manifold (mates with other Platinum sectional units) plus 1" rear gas connection.
  • Backed by Southbend’s 1-year parts & labor warranty and nationwide service network.
Performance Specifications
Overall width 48" (1219 mm)
Cook-top output 8 × 35,000 BTU open burners (280,000 BTU)
Oven type / rating Convection, 45,000 BTU • 175 °F – 550 °F thermostat
Total input 325,000 BTU/hr (natural or propane)
Oven cavity 14" H × 26" W × 24" D • 3 racks / 5 positions
Base storage 12" stainless cabinet (right side)
Gas connections 1-1/4" front manifold • 1" rear male NPT • 7" WC NG / 11" WC LP minimum supply
Construction Stainless steel front, sides, rear & exterior bottom; removable steel grates
Legs 6" stainless, adjustable
Certifications CSA • NSF
Ideal For
  • High-volume restaurants & diners
  • Hotel and resort kitchens
  • Catering & banquet operations
  • Institutional foodservice — universities, healthcare, corrections
Oversized cookware policy: Use pots or pans 12" or larger only on the rear grates to prevent excessive heat build-up on the front rail and avoid premature component damage.

Specifications and design are subject to change without notice. For commercial use only.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Platinum

Certifications

NSF, CSA

Height

41.0in

Width

48.0in

Depth

37.5in

Shipping Weight

621.0lbs

Top

(8) open burners

Base

(1) convection oven, (1) cabinet

Exterior Finish

stainless steel front & sides

Specifications

Platinum Heavy Duty Range, gas, 48", (8) 35,000 BTU open burners, manual controls, (1) convection oven, (1) 12" cabinet right, includes (3) racks, stainless steel front, sides, rear, exterior bottom & 6" adjustable legs, 325,000 BTU, CSA, NSF
