Southbend (Middleby) P36N-BGG Platinum Gas Ranges
Description
Southbend Platinum 36" Modular Heavy-Duty Range
2 Open Burners + 24" Manual Griddle • 134,000 BTUBuild a high-volume cook line without giving up precious floor space. The Platinum Series combination top pairs two powerful open burners with a full 24 inch griddle on a single 36 inch sectional frame, giving chefs immediate flame for sauté work and a broad, even cooking surface for pancakes, burgers, grilled cheese, and more. Because it’s a true modular unit, you can drop it onto a refrigerated base, equipment stand, or any Southbend sectional battery for a perfectly integrated suite.
Why You’ll Love It
- Flame on Demand — Two patented clog-free burners punch out 35,000 BTU each for lightning-fast heat and instant recovery.
- 1" Thick Steel Griddle — A 24 inch plate absorbs and distributes heat evenly; ideal for all-day breakfast or bulk prep.
- Battery Spark Ignition — Reliable push-button lighting eliminates standing pilots and saves gas.
- Built to Last — Heavy-gauge stainless steel front, sides, rear, and exterior bottom handle the daily punishment of busy kitchens.
- Chef-Friendly Design — 9-1/4" deep front rail doubles as plating/finishing space while keeping controls cool.
- Sectional Flexibility — 1-1/4" front manifold couples quickly to adjacent Platinum units; 1" rear NPT inlet simplifies final connection.
- Code Ready — cCSAus, CSA Flame, CSA Star & NSF listings—accepted coast to coast.
- Made in the USA — Fabricated and assembled in Fuquay-Varina, North Carolina.
Technical Specifications
| Model | P36-BGG (modular top) |
|---|---|
| Overall width | 36" (914 mm) |
| Overall depth | 40" (1,016 mm) |
| Cooking surface height* | 37-1/2" (953 mm) |
| Flue height | 5" (127 mm) |
| Total input | 134,000 BTU/hr (Natural) 126,000 BTU/hr (Propane) |
| Open burners | 2 × 35,000 BTU clog-free cast brass |
| Griddle section | 24" wide, 1" thick plate 2 × 16,000 BTU burners, manual control |
| Gas connection | 1-1/4" front sectional manifold 1" rear male NPT inlet Min. supply: 7" W.C. NAT / 11" W.C. LP |
| Electrical | None (battery spark ignition) |
| Construction | Stainless steel front, sides, rear & exterior bottom; fully-insulated burner box |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year parts & labor |
*Height will vary when unit is mounted on a cabinet, oven, or equipment stand.
Factory Options & Accessories
- 24" or 36" flue riser with single or double shelves
- Chrome-plated or grooved griddle surface
- External gas pressure regulator
- Open frame base with casters & restraint kit
- 7-1/4" deep “old-style” front rail or square belly bar
Upgrade your cook line with Platinum performance and the flexibility only a sectional range can deliver. Add the P36-BGG to your quote today—or talk to our specialists about building a complete Southbend battery that’s tailored to your menu.
