Southbend (Middleby)

Southbend Platinum 36-Inch Heavy Duty Gas Sectional Range with Three 12-Inch Uniform Hot Tops and Cabinet Base

SKU: P36C-HHH
$9,645.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Gas Ranges New Arrivals Ranges Restaurant Equipment Southbend (Middleby)

Southbend Platinum 36-Inch Heavy Duty Gas Sectional Range with Three 12-Inch Uniform Hot Tops and Cabinet Base

Manual Controls, Battery Spark Ignition, 96,000 BTU, Stainless Steel Construction

This 36-inch Platinum sectional range pairs three uniform hot tops with a rugged stainless steel cabinet base for dependable, high-output cooking in busy kitchens.

  • 36-inch wide gas sectional range with three 12-inch uniform hot tops
  • 96,000 BTU output for demanding commercial cooking
  • Manual controls with battery spark ignition for reliable startup
  • Stainless steel front, sides, rear, and exterior bottom
  • Cabinet base with removable center-opening doors for storage
  • 6-inch adjustable stainless steel legs and a 9-1/4-inch front rail

Overall Dimensions:

36.0"W x 37.5"D x 41.0"H

Product Weight:

490.0 lb

Three Uniform Hot Tops

The 36-inch cooking surface is divided into three hot-top sections for flexible pan placement and efficient production cooking.

96,000 BTU Output

High-output gas heat is rated at 96,000 BTU for heavy-duty commercial use.

Manual Controls with Battery Spark Ignition

Simple manual controls and battery spark ignition provide dependable operation without a line-voltage connection.

Stainless Steel Exterior

Front, sides, rear, and exterior bottom are stainless steel for durability and easier cleanup.

Cabinet Base Storage

The stainless steel cabinet base includes removable doors that open from the center for convenient under-unit storage.

Removable Steel Plates

Removable steel plates support a hot-top surface temperature up to 700°F on high.

Adjustable Stainless Steel Legs

Standard 6-inch adjustable stainless steel legs help level the range during installation.

Heavy-Duty Front Rail and Insulation

A 9-1/4-inch front rail and fully insulated lining and burner box support comfortable, efficient operation.

Type Sectional Range
Style Cabinet Base
Installation Type Floor Model
Controls Manual
Material Stainless Steel
Finish Polished Stainless Steel
BTU 96,000 BTU
Gas Connection Size 1-1/4 Inches Front Manifold; 1 Inch Rear Gas Connection
Gas Inlet Pressure 7 Inches W.C. Natural Gas; 11 Inches W.C. Propane
Shipping Width 36 Inches
Shipping Depth 38 Inches
Shipping Height 41 Inches
Shipping Weight 490 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1 year parts and labor

Documents

PDF Cutsheet PDF Download PDF Product configurator PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It has a full-width uniform hot top with three 12-inch sections and removable steel plates.
Yes. The cabinet base includes removable stainless steel doors that open from the center.
It uses a 1-1/4-inch front manifold and a 1-inch rear gas connection.
Minimum gas supply pressure is 7 inches W.C. for natural gas and 11 inches W.C. for propane. A pressure regulator must be ordered separately.
Minimum clearance from combustible construction is 10 inches on the sides and 12 inches on the rear. Installation under a vented hood is recommended.
The unit includes a one-year parts and one-year labor warranty from the date of original purchase.
