Southbend (Middleby) P32D-XX Platinum Gas Ranges
Description
Southbend Platinum Series 32" Heavy-Duty Gas Range
4 × 45,000 BTU Pyromax Burners • Standard Oven • 225,000 BTU Total OutputEngineered for high-volume kitchens that demand relentless performance, the Southbend Platinum P32D-XX delivers 225,000 BTU of cooking power in a compact 32" footprint. Four patented Pyromax™ open burners handle every sauté, sear, or stockpot with ease, while a full-size standard oven turns out perfectly baked, roasted, or finished dishes all day long.
Why You’ll Love It
- Four 45,000 BTU Pyromax burners – clog-free design for consistent flame & zero downtime.
- Manual, heavy-duty burner valves give chefs instant, precise control.
- 45,000 BTU standard oven with “Insta-On” thermostat (175 – 550 °F) and two adjustable racks.
- Sheet-pan friendly cavity (26" × 26.5") holds pans either direction for maximum flexibility.
- Stainless steel everywhere – front, sides, rear, and exterior bottom stand up to daily abuse.
- Removable welded steel top grates & drip tray speed up end-of-shift cleanup.
- 9-1/4" deep front rail keeps cookware within safe reach.
- 5" stainless flue riser vents heat away from the cook line.
- Six 6" stainless steel adjustable legs ensure rock-solid setup on uneven floors.
- Certified CSA & NSF for gas safety and sanitation.
Built for the Long Haul
- Fully insulated lining & burner box retain heat and protect surrounding components.
- 1-1/4" front manifold and 1" rear gas connection make battery installation simple.
- Free battery-design assistance direct from Southbend engineers.
- Backed by a 1-year parts & labor warranty and nationwide authorized service network.
At-a-Glance Specs
| Model | P32D-XX (Standard-Oven Base) |
|---|---|
| Gas Type | Natural or Propane |
| Total BTU | 225,000 BTU/hr |
| Open Burners | 4 × 45,000 BTU Pyromax™ clog-free |
| Oven Output | 45,000 BTU • Standing pilot • 175 – 550 °F thermostat |
| Oven Interior (H × W × D) | 14" × 26" × 26.5" |
| Racks Supplied | 2 (5-position side rails) |
| Exterior Dimensions (W × D × H) | 32" × 37.5" × 42.5" (to top of 5" flue) |
| Gas Connections | 1-1/4" front manifold • 1" rear NPT |
| Legs | 6" stainless steel, height-adjustable |
| Shipping Weight | ≈ 630 lb |
| Certifications | CSA, NSF |
| Warranty | 1 year parts & labor (commercial use) |
Popular Factory Options (Sold Separately)
- Electronic oven pilot ignition (no charge upgrade)
- 24" or 36" flue riser with single or double shelving
- Front rail cutouts for saucepans or square belly bar
- Open-frame or cabinet base with locking casters
- Battery spark ignition for open burners
- Stainless steel oven interior
Ask your Crandall Foodservice representative to configure the perfect range for your line-up.
