Southbend (Middleby) P32C-XH Platinum Gas Ranges
Description
Southbend Platinum Heavy-Duty 32" Range – 2 Open Burners & 16" Hot Top
Model P32C-XH | Natural / LP Gas | 130,000 BTUBuilt for demanding, high-volume kitchens, the Southbend Platinum Series P32C-XH combines two 45,000 BTU Pyromax™ open burners with a versatile 16" hot top, all on a rugged stainless-steel cabinet base. Battery spark ignition, clog-free burner design, and industry-leading heat output make this 32" sectional range a compact powerhouse you can bank on for years of reliable service.
Performance & Versatility
- (2) Signature Pyromax™ 45,000 BTU NAT (45,000 BTU LP) open burners – patented clog-free ports for consistent flame.
- Removable, welded-steel top grates and drip tray simplify daily cleaning.
- 16" heavy hot top with (2) 20,000 BTU NAT (18,000 BTU LP) burners under a one-piece plate; surface reaches ≈ 700 °F on high.
- Single high/low control knob for the hot top – excellent for holding, sautéing, stock pots and more.
- Battery spark ignition across all top sections; no standing pilots = lower energy costs.
Built to Last
- Stainless-steel front, sides, 5" flue riser and 9-1/4" deep front rail.
- Fully-insulated burner box for cooler side panels and improved efficiency.
- 6" stainless-steel adjustable legs for quick leveling under any hood line.
- Stainless cabinet base with two removable doors – ideal for pan, tray or small-wares storage.
- 1-1/4" front gas manifold with 1" rear NPT connection allows simple battery installation with other Platinum units.
Specifications
| Gas Type | Natural (field convertible to LP) |
|---|---|
| Total Input | 130,000 BTU/h |
| Open Burner Section | 90,000 BTU/h – two 45,000 BTU burners |
| Hot Top Section | 40,000 BTU/h – two 20,000 BTU burners |
| Width | 32" / 813 mm |
| Depth (overall) | ≈ 40" / 1,016 mm |
| Working Height | 36" to cook surface; 41" to top of 5" flue riser |
| Shipping Weight | Approx. 440 lb / 200 kg |
| Gas Connection | 1" NPT (rear) Minimum supply – 7" W.C. NAT | 11" W.C. LP |
| Certifications | CSA, NSF |
| Warranty | 1 year limited parts & labor (Heavy-Duty Sectional Range) |
Included
- Factory-installed battery spark ignition (AA battery not included).
- Removable steel hot-top plates.
- (2) welded open-top grates & drip tray.
- Operator’s manual and quick-start guide.
Popular Options (sold separately)
- External gas pressure regulator.
- 24" or 36" stainless flue riser with optional shelving.
- Front rail cut-outs for saucepans or square belly bar.
- Locking swivel casters or open-frame base with casters.
