Southbend (Middleby) P24C-BB-SU Platinum Gas Ranges
Description
Southbend Platinum 24" Heavy-Duty Gas Range – Step-Up, 4 Burners
Model P24C-BB-SU | 140,000 BTU Total OutputPurpose-built for high-volume kitchens, the Southbend Platinum Series 24" Step-Up Range delivers four clog-free open burners—two standard in front and two elevated 4" in back—for maximum cooking versatility in a compact footprint. A rugged stainless steel cabinet base, manual controls, and heavy-duty components make this unit the go-to choice for restaurants, hotels, and institutional operations that demand uncompromising performance shift after shift.
Highlights
- Four 35,000 BTU open burners (140,000 BTU total)
- Rear burners sit 4" higher for easy stock-pot access and multi-pan staging
- Patented clog-free burner design with removable welded-steel top grates
- 9-1/4" deep front rail and full-width drip tray simplify cleanup
- All-stainless exterior: front, sides, rear, and bottom
- Stainless cabinet base with two center-opening doors—ideal for pan, pot, or sheet-tray storage
- 5" stainless flue riser (standard) directs heat up and away from the cookline
- Manual, gas-only controls—no electricity required
- 6" stainless steel legs, height-adjustable for a perfect, level install
- cCSAus, CSA Flame, CSA Star & NSF certified; Made in USA
Technical Specifications
| Width | 24" / 610 mm |
|---|---|
| Depth (with 5" flue) | 34" / 864 mm |
| Height to Cooktop | 36" / 914 mm |
| Overall Height (incl. flue) | 41" / 1 041 mm |
| Total BTU | 140,000 BTU/hr (4 × 35,000 BTU) |
| Gas Type | Natural or Propane (field convertible, specify at order) |
| Gas Connections | 1 ¼" front manifold; 1" rear male NPT |
| Cabinet Base Capacity | Full-width storage with two removable doors |
| Shipping Weight | ≈ 400 lbs / 181 kg |
| Clearances (Combustible Surfaces) |
10" sides • 6" rear |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year limited parts & labor |
Factory Options & Accessories (sold separately)
- External gas pressure regulator
- Locking casters or open-frame base with casters
- 24" or 36" flue risers with optional utensil shelves
- Tray or tubular shelving (12" deep)
- Battery spark ignition for multi-unit line-ups
- Cable restraint kit for mobile installations
Intended for commercial use under a properly ventilated hood. Follow local codes for installation and service.
