Southbend (Middleby) P24C-BB Platinum Gas Ranges
Description
Southbend Platinum Series 24" Heavy-Duty Gas Range
Model P24C-BB | 4 Open Burners | 140,000 BTU TotalEngineered for high-volume, 24/7 kitchens, this Platinum Series range squeezes four 35,000 BTU clog-free burners into a space-saving 24" footprint while delivering the indestructible stainless-steel build chefs expect from Southbend.
Performance & Construction Highlights
- (4) 35,000 BTU open-top burners – 140,000 BTU/hr combined
- Patented clog-free burner design with removable welded-steel grates
- Manual, front-mounted burner controls for instant flame adjustment
- 9-1/4" deep stainless-steel front rail with removable drip tray
- Fully insulated burner box keeps exterior surfaces cooler
- 5" stainless flue riser directs heat safely into your hood system
- All-stainless exterior (front, sides, rear & bottom) resists corrosion
- Stainless cabinet base with two center-opening doors for storage
- 6" adjustable stainless legs ensure a level installation
- Battery-ready 1-1/4" front gas manifold for seamless line-ups
- cCSAus, CSA Flame, CSA Star & NSF certified
Built for Your Cookline
- Sectional design means you can expand or re-configure as your menu grows.
- Free battery-layout assistance from Southbend engineers ensures a perfect fit.
- One-year parts & labor warranty backed by a nation-wide service network.
Specifications
| Exterior dimensions (W × D × H) * | 24" × 41" × 41" (with 5" flue) |
|---|---|
| Work height | 36" to cooking surface |
| Open burners | 4 clog-free brass |
| BTU per burner | 35,000 BTU (Natural or LP) |
| Total input | 140,000 BTU/hr |
| Gas connection | 1-1/4" front manifold / 1" rear male NPT |
| Required gas pressure | 7" W.C. Natural / 11" W.C. Propane |
| Base type | Stainless cabinet, double doors |
| Legs | 6" adjustable stainless steel |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1 year parts & labor |
| Shipping weight | ≈ 400 lb / 181 kg |
* Dimensions shown are for the standard 5" flue riser. Height increases to 43-1/2" with the optional 36" flue.
Popular Options (ordered separately)
- 24" or 36" flue risers with single or double shelves
- Step-Up rear burners (+4" elevation)
- Battery spark ignition
- Casters (front locking) & restraining cable kit
- External gas pressure regulator
- Tubular or tray shelves, removable interior shelf
Planning a full battery or multi-unit purchase? Ask about Middleby Equipment Financing to turn large purchases into predictable monthly payments.
