Description

Southbend Platinum Series 12" Modular Heavy-Duty Gas Range with Manual Griddle

Model P12N-G  |  32,000 BTU Total

When kitchen space is tight but performance can’t be compromised, choose the Southbend Platinum P12N-G. This 12" sectional griddle module delivers big-range muscle in a footprint that drops seamlessly into any Southbend battery or countertop layout. A full-inch thick plate, rugged stainless construction, and simple manual controls make it the dependable workhorse for breakfast lines, short-order menus, and chef-driven finishing stations.

Key Features

  • Full-width griddle powered by two 16,000 BTU burners (32,000 BTU/hr natural gas).
  • 1" (25 mm) thick polished steel plate for superior heat retention and fast recovery.
  • Manual single-knob control with reliable Piezo electronic pilot ignition.
  • Integrated side & rear splashguards plus removable stainless steel grease drawer.
  • 5" stainless-steel flue riser keeps heat and combustion gases off the cook line.
  • All-stainless exterior (front, sides, rear, bottom) with fully insulated liner & burner box.
  • Front 1-1/4" manifold couples to adjacent sections; rear 1" NPT gas inlet for stand-alone use.
  • Zero clearance to non-combustibles; 10" side / 12" rear clearance to combustibles.
  • Certified cCSAus, CSA Flame, CSA Star & NSF for safety and sanitation.

Specifications

Cooking surface 12" W x 24" D full-width griddle
Total BTU 32,000 BTU/hr (Natural)  |  28,000 BTU/hr (Propane)
Plate thickness 1" (25 mm)
Gas connection 1" NPT rear; 1-1/4" front manifold
Supply pressure 7" W.C. Natural  |  11" W.C. Propane (regulated)
Overall width 12" (305 mm)
Overall depth 37-1/2" (953 mm)
Overall height 41" (1,041 mm) to top of 5" flue riser
Shipping weight 175 lb (79 kg)
Agency listings cCSAus, CSA Flame, CSA Star, NSF
Warranty 1 year parts & labor

Popular Options & Accessories (sold separately)

  • External gas pressure regulator
  • Locking casters or open-frame base with casters
  • 7-1/4" deep or cut-out front rail configurations
  • 24" or 36" flue riser with optional 10" shelves
  • Grooved or chrome-plated griddle surface
  • Cable restraint kit for mobile installations

Shipping & Installation Notes

  • Ships in one crate: 20" W x 21" H x 42.5" D (10.3 cu ft).
  • Unit requires installation under a vented hood by a qualified technician.
  • A regulated gas supply is mandatory; order regulator if not already on site.
  • If a flexible gas hose is used, an ANSI Z21.69 approved restraining device must be installed.
Important: Manual griddles are non-thermostatic and will not maintain a specific set temperature. Use a surface thermometer to verify plate temperature for critical menu items.

Commercial use only  |  Not for residential installation.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Platinum

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

13.5in

Width

12.0in

Depth

37.5in

Shipping Weight

175.0lbs

Top

(1) griddle

Base

modular

Exterior Finish

stainless steel front & sides

Plate Thickness

1.000" = 1"

Specifications

Platinum Heavy Duty Range, gas, 12", modular, griddle, 1" thick plate, manual controls, piezo ignition, side & rear splashguards, stainless steel front, sides, rear & exterior bottom, 32,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
