Southbend Platinum Heavy Duty 12-Inch Modular Natural Gas Full-Width Charbroiler

Sectional Design, Cast Iron Grates, Manual Controls

Compact 12-inch modular charbroiler delivers 32,000 BTU of natural gas heat with heavy-duty stainless steel construction and reversible cast iron grates.

  • 12-inch modular charbroiler built for sectional or battery-style commercial installations.
  • 32,000 BTU natural gas output with manual high/low heat control.
  • Full-width cast iron grates flip for 1/8-inch or 1/4-inch grid width and adjustable slope.
  • Stainless steel construction and burner radiants support durability and even heat.
  • Removable drip tray and insulated burner box help simplify cleanup and improve performance.
  • Can be mounted on a countertop, refrigerated base, or freezer base.

Overall Dimensions:

12.0"W x 37.5"D x 13.5"H

Product Weight:

175.0 lb

Full-Width Charbroiler Surface

Compact 12-inch wide charbroiler provides a full-width cooking surface for high-volume searing in a small footprint.

Natural Gas Burners

Two 16,000 BTU natural gas burners deliver 32,000 BTU total output.

Reversible Cast Iron Grates

Removable cast iron grates adjust front-to-back slope and flip to provide either 1/8-inch or 1/4-inch grid width.

Stainless Steel Burner Radiants

Stainless steel radiants help distribute heat and support consistent broiling performance.

Manual High/Low Controls

Simple manual control knob provides straightforward heat adjustment.

Stainless Steel Construction

Front, sides, rear, and exterior bottom are constructed of stainless steel for commercial durability.

Removable Drip Tray

Drip tray can be removed for easier cleaning and maintenance.

Insulated Burner Box

Fully insulated lining and burner box help retain heat and support efficient operation.

Standard Front Rail And Flue Riser

Includes a 9-1/4-inch deep front rail and a 5-inch high stainless steel flue riser.

Type Charbroiler
Style Sectional
Installation Type Countertop (Modular Mount)
Controls Manual
BTU 32,000 BTU
Gas Type Natural Gas
Gas Connection Size 1-1/4 Inches Front Manifold / 1 Inch Rear Gas Connection
Gas Inlet Pressure 7 Inches W.C. Minimum
Material Stainless Steel
Finish Stainless Steel
Country of Origin USA
Selling Unit Each
Units Per Case 1
Shipping Width 20 Inches
Shipping Depth 42.5 Inches
Shipping Height 21 Inches
Shipping Weight 175 Lbs.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1 year parts and labor

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

This is the modular mount version, designed for installation on a countertop, refrigerated base, or freezer base.
It is a natural gas model with 32,000 BTU total output.
It uses removable cast iron grates that flip for either 1/8-inch or 1/4-inch grid width.
Yes. It uses manual high/low controls.
The unit has a 1-1/4-inch front manifold and a 1-inch rear gas connection, and it requires a regulated gas supply.
Yes. Installation under a vented hood is recommended.
