Southbend (Middleby) P12C-H Platinum Gas Ranges
Description
Southbend Platinum 12" Heavy-Duty Gas Range – Uniform Hot Top
Model P12C-H | Cabinet Base | 32,000 BTUPut uncompromising power exactly where you need it. The Platinum 12" Hot Top Range drops seamlessly into any Southbend battery, delivering a 700 °F steel cooking surface in less than one square foot of line space.
Key Performance Features
- Full-width 12" uniform steel hot top powered by 2 × 16,000 BTU burners (32,000 BTU total).
- Manual infinite high/low valve with dependable piezo-electric pilot ignition.
- Removable hot-top plates for rapid daily cleaning and easy service access.
- Up to 700 °F (371 °C) surface temperature—ideal for stock pots, reductions and sauté work.
- All-stainless exterior (front, sides, rear & bottom) resists dents, corrosion and harsh chemicals.
- 5" stainless flue riser efficiently channels heat into the hood system.
- Battery-ready 1-1/4" front gas manifold and 1" rear NPT connection.
- Stainless cabinet base with reversible door adds convenient dry storage.
- 6" adjustable stainless legs for fast leveling on uneven floors.
- Safety & compliance: CSA Flame, CSA Star, cCSAus and NSF listed.
Specifications
| Cooking surface | 12" W full-width uniform hot top |
|---|---|
| Total BTU input | 32,000 BTU/hr (Natural or Propane) |
| Controls | Manual high/low valve & piezo pilot ignition |
| Overall dimensions* | 12" W × 37.5" D × 41" H (with standard 5" flue) |
| Cooking height | 33-3/4" |
| Gas connection | 1-1/4" front manifold; 1" rear male NPT |
| Min. supply pressure | 7" WC Natural | 11" WC LP |
| Shipping weight | ≈ 180 lb (81.6 kg) |
| Clearances | 0" sides/rear (non-combustible) | 10" sides & 12" rear (combustible) |
| Warranty | 1-year parts & labor (commercial use) |
*Consult spec sheet for detailed dimensional drawings.
Popular Factory Options
- 24" or 36" flue risers with utensil shelves
- Locking front casters or open-frame base with casters
- Pressure regulator & gas-hose restraint kit
- Front-rail cut-outs or square belly bar
For best results, position cookware 12" or larger toward the rear of the hot top to prevent excess heat on the front rail. Intended for commercial use only — not for household installation.
